Home > Products > Air Compressor Valve > Coil Gas Atlas Copco Air Compressor Solenoid Valve 110v Normal Closed Type 1089070213
Coil Gas Atlas Copco Air Compressor Solenoid Valve 110v Normal Closed Type 1089070213
US$ 30 - 40
/ Piece
1 Piece(Min. Order)
- shenzhen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Pneumatic Drain Valve PA-68 Auto Drain Valve Air Compressor Part PA-68 Portable Wireless PA Amplifier
-
CEME 220V Atlas Copco Air Compressor Solenoid Valve 1/2 Inch Normally Open
-
Rubber Blow Off Valve for Atlas Copco Screw Air Compressor 1622369480
-
Fusheng Air Compressor Parts Compressor Thermostat Valve TV3 TV6
-
Rotary Air Compressor Equipment 1/2" Thread Solenoid Valve 24V/220V
-
Solenoid Valve 220v ac Atlas Copco Screw Compressor Spare Parts Compressor Valve
Product Details
| Place of Origin | China | Brand Name | ATLAS COPCO | |
| Model Number | 24V / 110V / 220V | Type | Valve |
Product Description
Product Description
Coil Gas Atlas Copco Air Compressor Solenoid Valve 110v 2W 2S Normal Closed Type 1089070213
atlas copco replacement solenoid valve 24v
solenoid valve for 110v 24v 220 v
atlas copco spare parts solenoid valve 24v air compressor part
atlas copco solenoid valve 24v
air compressor part solenoid valve 24v
List of part number
| Working Medium | Air, Water, Oil, Gas |
| Operating Principles | Direct Action |
| Type | Normal Closed Type |
| Operation Fluid Viscosity | ≤20 CST) |
| Suitable temperature | -5~80℃ |
| Voltage Range | ±10% |
| Material of Valve Body | 2W:Brass; 2S:Stainless Steel |
| Material of Oil Seal | NBR,EPDM or VITON |
Compressor parts --- solenoid valve
| Characteristic | 1.Pilot operated diaphragm structure with less power comsumption for long time working |
| 2.Applied to pressure system opened from 0.03 Mpa | |
| 3.Life span can be over 1 million times | |
| Medium | Air, water etc. |
| Temperature | NBR:-10°C to 80 °C |
| EPDM:-10°C to 120 °C | |
| VITON:-10°C to 150 °C | |
| Pressure | 0.03-1.6Mpa |
| Port size | 3/8'-1' |
| Port thread | G.BSPT,BSP,NPT,PT |
| Orifice | 12,15,20,25mm |
| Voltage | DC-12V,24V |
| AC-24V,120V,240V/60HZ,110V,220V/50HZ | |
| Tolerance | ±10% |
| Coils | SA11B,9VA(AC),6W(DC) IP 65,100% ED |
| S91B,22VA(AC),17W(DC) IP65,100% ED | |
| Special coils | Latching coil:DC6-24V as requested |
| Material | Body- brass or stainless steel |
| Seal- NBR,EPDM,VITON | |
| Amature tube-stainless steel 304 | |
| Plunger-stainless steel430F | |
| Stop-stainless steel 430F | |
| Springs-SS304 | |
| Shading rings- stainless steel 304 |
FAQ
Q1: How can I get the quotation?
A: you can advise us the part number for checking, and we will quote to you soon by email
Q2: What kind of ways for transportation ?
A:In general by air, sea or Express.(like DHL,Fedex,TNT,etc.)
Q3: How do I know the quality of productions?
A:We have a strict series of quality control, and we have perfect after service system, which can help you to solve the problem soon
Q4: If i want to change model,size,package,etc. How can I do?
A:You can contact us by skype or mail, and we will revise according to your requirement
Q5: What is the terms of payment ?
A: T/T, Western Union, paypal(need 5% paypal fee)
