SMD3030 1.5W Samsung 12V DC LED Module for backlight channel letter, lighting box

FOB Price

US$ 0.29 - 0.29 / Piece

1000 Pieces(Min. Order)

Port Hongkong or Shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Model Number	HL-ME04S	Chip Material	Other, ABS Injection
Emitting Color	Other, White	Luminous Intensity	10000
Luminous Flux(lm)	140lm	Optical Attenuation(%)	1
Power	Other, 1.5W	Power Dissipation	1.5W
Color Rendering Index(Ra)	80	Color Temperature	10000-12000K
Operating Temperature(℃)	-20, 50	Storage Temperature(℃)	-30, 80
Place of Origin	Guangdong, China	Brand Name	iledhl
Certification	CE, CE

Product Description

Product Introduction

(1) 1.5W/LED

(2) Use Samsung SMD3030 1.5W high power chipset

(3) Warm white: 3000-3200K White: 6000-6500K Cool White: 10000-12000K, Red, Yellow, Blue, Green, Pink all available for this type

(4) Consumption: 1.5W

(5) DC12V input

(6) IP level: IP65

(7) 20pcs as a series

(8) Working temperature : -20~50 degree

(9) Packing : 100pcs / bag , 10bags / Carton

(10) Color: Warm white, White, Cool White, Red, Yellow, Blue, Green, Pink supported

(11) Offer ODM service and also the high brightness customrized strip for the project

(12) Easy installation : self adhersive

(13) Extended life : more than 30,000 hours

(14) Evironmental friendly : with CE / RoHS certificate, more than 60% more energy efficient than Neon

(15) Safe application : Low voltage DC12V, safe and stable, free maitenance

Product Specification

Model	HL-ME04S
LED Type	1LED Samsung SMD3030
Warranty (years)	3
Emitting Color	10000-12000K
Beam Angle (°)	160° with lens
Lumen(LM)	Red	Green	Blue	Yellow	WW	NW	CW
	/	/	/	/	120	130	140
Wave Length (nm/Kelvin)	620-625nm	520-530nm	465-470nm	585-595nm	3000-3200K	6000-6500K	10000-12000K
Chip Qty (chips)	1
LED Chip Life (H)	50,000
Electrical Parameter	Working Input Voltage (V)			DC12V
	LED Power (W)			1.5W
	Working Input Current (mA)			125mA
	Drive Mode			Constant Voltage
Features of Connection and Series	Interface: 1007 20AWG; Externl diameter: 1.8*100mm combined wire of white & red color
	Standard quantity of a series			20 pcs
	Max quantity of a series			20 pcs
Physical Parameter	Diamension			43.8288mm
	Housing Color			White
	Housing Material			ABS ABS & epoxy resin Injection
	Affixing way			FB1610PE 3M double-sided adhersive tape & 4 screws or rivets with diameter of 3.0-4.0 mm
	Weight			12g
Enviromental Parameter	Working Temperature			-40°F- 122°F (-40°-50° C)
	Storage Temperature			-58°F- 140°F (-50°-60° C)
	Operating Humidity			10% - 95%, non-condensing
	IP Rate			IP65 waterproof
Packing	Qty/ctn			20pcs/bag,1000pcs/ctn
	Ctn Size			50x25x27cm
	G.W./Ctn			12.92KG
	CBM/Ctn			0.04m3

Product Details

Installation:

Certification:

Application Project:

1 Channel letter

2 Advertisements sign

3 KTV,Disco

4 LOGO, advertising billboard,exposed luminous characters

5 LED display screen
