Supermaly water cooled 200Kva open type diesel generator by 6CTAA8.3-G2
- Qingdao Port
- T/T
You May Like
-
Prime power generator diesel 300kva with price
-
New design reliable 30kw to 500kw electric generator
-
New design 20kw to 500kw generators diesel
-
Hot ! chinese manufacturing company generator with yuchai engine
-
Hot ! low noise standby power plant for sale electricity plant
-
Hot ! Supermaly Ricardo backup generator 20-250kw
Product Details
Place of Origin | Shandong, China | Brand Name | Supermaly | |
Model Number | SC200GFS | Output Type | AC Three Phase | |
Speed | 1500/1800rpm | Frequency | 50HZ/60HZ | |
Rated Power | 160KW/200KVA | Rated Voltage | 400/230V | |
Rated Current | 288A |
Product Description
SPECIFICATION OF WATER COOLED 200KVA OPEN TYPE DIESEL GENERATOR BY 6CTAA8.3-G2
Generator Set Model | SC200GFS |
Type | OPENTYPE |
Genset Output Power | 160KW/200KVA |
Rated Voltage | 400/230V |
Frequency | 50HZ |
Power factor | 0.8 |
Rated speed | 1500rpm |
Output type | AC three phase/single phase |
Motor | brushless |
Frequency | <3% |
Frequency at stable state: | <0.5% |
Frequency deviation at instantaneous state | ≤+10% |
Frequency return time | ≤3s |
Voltage deviation at stable state | ≤±1% |
Voltage deviation at instantaneous state | ≤+20% |
Voltage return time | ≤4s |
Voltage modulation | ≤0.3% |
ENGINE OF WATER COOLED 200KVA OPEN TYPE DIESEL GENERATOR BY 6CTAA8.3-G2
Model | 6CTAA8.3-G2 |
Rated Power | 183KW |
Cyl/Bora/Stroke(mm) | 6/114/135 |
Cooling Method | water cooled |
Rotating Speed | 1500/1800rpm |
Governor System | electrical or mechanical governor |
Aspiration Mode | turbocharged |
Starting Method | 24DC electric starting |
Stroke | 4 stroke |
ALTERNATOR OF WATER COOLED OPEN TYPE DIESEL GENERATOR BY 6CTAA8.3-G2
Brand | STANMFORD |
Rated Power | 160KW/200KVA |
Regulator | AVR Automatic Voltage Regulating |
Excite Type | pret or shunt |
Connecting Type | 3PH star, 3PH-DELTA |
Steady Frequency Change | 0-5% |
No Load Voltage | ≥95%-105 |
Steady Voltage | ≤±1 |
Insulation Degree | H degree |
Exclosure Degree | IP23 |
Generator set Features:
1. Cummins industrial diesel engine
2. Radiator 40°C max,fans are driven by belt, with safety guard
3. Choice of manual/auto and AMF control panels and protection systems
4. Digital auto-start panel
5. Anti Vibration Suspension Absorber
6. Dry type air filter, fuel filter, oil filter
7. Mould case circuit breaker
8. 24V DC start motor and storage battery
9. Ripple flex exhaust pipe, exhaust siphon, flange, and muffler
Packed with wrapped film as standard,plywooden case for options
When we finished the test of diesel generator,our transporation department then will take charge
of sending the generator to the container at port of loading,with help of our excellent forwarder,
we send our generators to our customers successfully without any damage.
Warranty policy of power generator set:
Guarantee for one year or 1500 hours whichever reach first from ex-factory date.
During the guarantee period, we will provide the free easy-damageable spare parts of diesel engine caused by our quality of production or raw material.
After expiration, we provides cost spare parts maintenance of gensets
OEM Service of power generator set:
We can provide professional OEM Service for customers.
1. Unique design and manufacture of generator according to customers requirement.
2. Customer logo printing or painting on the genset.
3. Installation and Operation manual neutral or headings can be design according tocustomer requirement.
4. Full warranty cover to support customers
1. What is your warranty period?
Our payment terms is 1 year or 1500 running hours whichever comes first. But based on some special project, we can extended our warranty period.
2. Does your generator have global warranty?
Yes, most of our products like Doosan, Yuchai, Deutz, Volvo power generator enjoy the global warranty service. And the alternator we use like Leroysomer, Stamford, marathon also enjoy the global warranty service, so you do not need to worry about the aftersales service.
3. Can you accept OEM?
Yes, we can accept OEM.
4. What is your payment terms?
We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight, L/C deferred payment terms or west union.
5. What is your delivery time?
Our normal delivery time is 15-20 days. But if your order is some special engine and alternator, then the delivery time is longer.
