hydraulic block

Specifications

  Our differences:

      Honcha - Biggest block machine manufacturing base and most reputable block machinery manufacturer  in china

     Offering first-rate prducts , best after-sales services and reasonalble competitive prices:

Products gained ISO 9001;2000,ISO14001;2004 and CE certificates

     Using reliable certified international brands for key parts of the machine ( such as the PLC system ) from Siemens ,Omron ,Mitsubishi,Emerson and Dakin

     Product advice service and complete factory projects including assembly and commissioning by our own qualified technicians

     Fluent English,Russian ,Chinese Mandarin and Cantonese services to completely understand our customer needs .

     The MULTI-FUNCTIONAL Honcha block machineries are designed to meet the mass production of various kinds of blocks ,such as pavers, hollow blocks, kerbstones, interlocking bricks, plantable blocks, retaining blocks and slope stones and so on by CHANGING MOULDS ONLY.

    The QT9-15 block machine techinacal data are as follows:

           Moulding cycle: 11-20s( extra 5-8s for face mix)

           Production capacity:22.5m3/hour

           Pallet dimensions:1380×680×30mm

           Effective moulding area:1280×600mm

           Product height:30-200mm

           Overall dimensions:6100×3500×2950mm

           Gross weight:appro10.5t

            Vibration frequency:2900-5600r/min

            Excitation force:50-90kn

           Total power:43.18kw

           Rated compressive strength:12-25mpa

      The QT6-15E block machine techinacal data are as follows:

          Moulding cycle: 15s( extra 5-8s for face mix)

          Pallet dimensions:1380×580×30mm

          Effective moulding area:1200×550×40-200mm

          Product height:30-200mm

          Overall dimensions:6000×3500×2950mm

          Gross weight:appro.9.6T

          Vibration frequency:280-4000r/min

          Excitation force:75kn

          Total power:33.38kw

          Rated compressive strength:12-25mpa
