Product Details
| Place of Origin | China | Brand Name | ZTE Versa/Versatek/VersaXpress | |
| Model Number | EC90EA |
Product Description
Product Overview
The EC90EA is an integrated outdoor cabinet. The cabinet is environmentally-friendly thanks to its low power consumption. It dissipates heat through a passive cooling tube.
Customer Benefits
Application scope
The EC90EA is applicable for small-capacity nodes. It can be used outdoors in temperate and subtropical zones as well as in corridors and equipment rooms without air-conditioning.
Product characteristics
The high strength shell material of the EC90E ensures normal running against 60 m/s strong winds. The surface of the main components is treated using a special technique to make it highly resistant to corrosion. The cabinet uses inner connection and inner fixture methods with no screw exposed to the outside. It features an anti-theft design with high strength locking buckles. A door access switch is equipment to work with the monitoring system to generate alarms in times of illegal intrusions. The components of the integrated rack are made of high quality, highly anticorrosive steel plates that are bent into shape and securely welded.
Product Specifications
Dimensions: 500 mm x 588mm x 350mm (Height x Width x Depth)
Capacity: 1 ZXDSL 9806H
Material: Steel plate
Weight: 24kg
Working temperature: -30°C~+55°C
Working humidity: 5%~100%
