Home > Products > Powered by Lovol > Hot Sale BOBIG Water Cooled Diesel Generator Set Powered by Lovol 72kw
Hot Sale BOBIG Water Cooled Diesel Generator Set Powered by Lovol 72kw
Negotiable
/ Set
1 Set(Min. Order)
- FUZHOU
- T/T
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | BOBIG | |
| Model Number | BL100 BL100S | Speed | 1500RMP | |
| Frequency | 50HZ | Rated Power | 24 | |
| Rated Voltage | optional |
Product Description
Diesel Generator 100kva generator LOVOL water cooled engine from 24kw to 110KW
Specifications
OEM,LOVOL 100kva generator
1.Original LOVOL generator engine
2.original stamford 100kva generator
3.CE,ISO9001
| 1) Output range: 24KW - 110kW diesel generator set |
| 2) Engine model: 1003G,1003TG,1004G,1004TG,1006TG3A,1006TG2A,1006TAG |
| 3) Alternator: Stamford, Leroy Somer, Marathon series |
| 4) Water-cooled |
| 5) 8hrs operation base tank |
| 6) Key start / auto start |
| 7) Sound-proof / weather-proof canopy is optional |
| 8) 230 / 400V AC, 50Hz / 60Hz, 0.8pF three-phase and four wires alternating current output |
| 9) Frequency: <3% |
| 10) Frequency at stable state: <0.5% |
| 11) Frequency deviation at instantaneous state: ≤+10% |
| 12) Frequency return time: ≤3s |
| 13) Voltage deviation at stable state: ≤+ -1% |
| 14) Voltage deviation at instantaneous state: ≤+20% |
| 15) Voltage return time: ≤4s |
| 16) Voltage modulation: ≤0.3% |
| 17) Standard configuration of gensets: |
| A) Engine: LOVOL diesel engine diesel generator set |
| B) Engine type: Water-cooled, in line four-stoke, dry cylinder liner, direct injection |
| C) Alternator: Brushless and "H" class insulation |
| 18) Control system: |
| A) Automatic alarm system: The unit has the acousto-optics alarm system and |
| Arrestor for any situation as the start defeat, the water is over temperature, |
| The oil pulls down, over speed, over load and over current |
| B) Operation display: |
| I) Unit voltage, tri-phase load current and frequency display |
| Ii) Water temperature, oil pressure display |
| Iii) Fuel level, fuel temperature display |
| Iv) Audible and visual alarm lamps and buzzers |
| 19) Starting system: DC alternator is used to start engine |
| 20) Short circuit protection: MCCB air switch |
| 21) Cooling system: Combined cooling water tank fitted to meet the requirement of radiation at ambient temperature 40 degree |
| 22) Filter system: Oil, fuel and air filter |
| 23) Accessories: Exhaust elbow, bellow, muffler |
| 24) Supply standard collocation: |
| A) Diesel engine with all accessories, 3 filter, electric systems |
| B) Alternator |
| C) Steel structure |
| D) Fan and water tank cooling system |
| E) Flange connector |
| F) 12 / 24V starting motor and charge engine |
| G) Air cleaner, fuel cleaner, oil cleaner |
| H) On-board control panel |
| Warranty:Guarantee for one year or 1200hours from ex-factor date.During the repair time,BOBIG COMPANY will provide the free easy-damageable spare arts of diesel engine caused by our quality of production or raw material.After expiration,BOBIG COMPANY will supply cost spare part for you to repair it. |
| Manufacturing standard: |
| ISO9001,EPA,CE and ....... |
| For more detail information,pls feel free to contact with us. |
