OEM 5kw to 30kw Kubota Generator
US$ 999 - 9,999
/ Unit
1 Unit(Min. Order)
- Fuzhou Ningbo Xiamen
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | BOBIG | |
| Model Number | Kubota Generator BK | Output Type | AC Three Phase | |
| Speed | 1500/1800RMP | Frequency | 50/60HZ | |
| Rated Power | 8KW TO 30KW | Rated Voltage | 230 240 220/127V 400/230V 380/220V | |
| Rated Current | 36A-1800A |
Product Description
Specifications
Kubota Generator1.Brushless alternator
2 Kubota engine
3.Rated power 8kw to 30kw
4.CE EPA ISO certificate
Silent Generator with Kubota Engine
These industrial generators are suitable for prime power and standby use,Everything is automatic. Power fails, generator turns on.Power is restored, generator shut off. That simple!
These industrial generators are suitable for prime power and standby use,Everything is automatic. Power fails, generator turns on.Power is restored, generator shut off. That simple!
BOBIG KUBOTA series
| KUBOTA series diesel generator water cooled | |||
| Specification data | |||
| Genset model | BK17S | ||
| Prime Power | 12KW/15KVA | ||
| Standby Power | 13.2/17 | ||
| KUBOTA ENGINE | Model | D1703-BG | |
| Type | Vertical 4 cycle liquid cooled Diesel | ||
| No.of Cylinders | 3 | ||
| Bore*Stroke mm(in) | 87.0*92.4(3.43*3.64) | ||
| Displacement | 1.647(100.51) | ||
| Combustion System | E-TVCS | ||
| Intake System | Natural aspirated | ||
| Fuel Injection Pump | Bosch type PFR MD pump | ||
| Direction of Rotation | Counterclockwise(viewed from flywheel side) | ||
| Injection Nozzle | Throttle type | ||
| Compression Ratio | 23 | ||
| Lubricating Oil | Quality better than CD class | ||
| Oil Pan Capacity L(gal) | 7.0((1.85) | ||
| Cooling System | Radiator cooling | ||
| Starter Capacity V-A | 12-1.2 | ||
| Alternator Capacity V-A | 12-40 | ||
| Used Fuel | Diesel Fuel No.2-D(ASTM D975) | ||
| Dry Weight kg(lbs) | 148.0(326.3) | ||
| Leroy Somer Alternator | Alternator Model | LSA 40 VS3 | |
| Alternator manufacturer | Leroy Somer | ||
| Exciter type | Single bearing ,Brushless,Self-excited | ||
| Prime power | 12kw/15KVA | ||
| Rated speed | 1500RPM | ||
| Rated frequency | 50Hz | ||
| Phase | 3 | ||
| Rated Voltage | 400V/230V(Available with customer requirements) | ||
| Power factor | 0.8 | ||
| Voltage adjust range | 5% | ||
| Voltage regulation NL-FL | -0.01 | ||
| Insulation grade | H | ||
| Protection grade | IP23 | ||
Quality finished Enclosures
Generator enclosures are solid structures designed on CAD Systems (Computer Aided Design). Laser cutting machines cut the different shapes out of heavy sheet metals.After the components are precision welded, they undergo a chemical cleaning process. The next step is electrostatic painting. Electrostatic force pulls paint around corners and edges ensuring a smooth, automotive quality finish.
Generator enclosures are solid structures designed on CAD Systems (Computer Aided Design). Laser cutting machines cut the different shapes out of heavy sheet metals.After the components are precision welded, they undergo a chemical cleaning process. The next step is electrostatic painting. Electrostatic force pulls paint around corners and edges ensuring a smooth, automotive quality finish.
Affordable High Quality
BOBIG generators are designed for many applications where power is needed. BOBIG generators are manufactured to commercial specifications using the latest manufacturing technologies. All models are built with the quality and reliability you would expect from a leading generator manufacturer.
BOBIG generators are designed for many applications where power is needed. BOBIG generators are manufactured to commercial specifications using the latest manufacturing technologies. All models are built with the quality and reliability you would expect from a leading generator manufacturer.
Easy To Use
The generator is remarkably easy to use. Just press the green button to start and the red button to stop. Advanced engine monitoring and control is achieved by using the Harsen GU641B controller
The generator is remarkably easy to use. Just press the green button to start and the red button to stop. Advanced engine monitoring and control is achieved by using the Harsen GU641B controller
Fully Automatic
Imagine the power fails and everything goes dark. Your not worried. Because your generator has a automatic transfer switch, it safely connects itself to your home and disconnects when the normal utility power is restored. Within seconds your power is back online and powering your whole home. You can leave your home knowing it is protected.
Imagine the power fails and everything goes dark. Your not worried. Because your generator has a automatic transfer switch, it safely connects itself to your home and disconnects when the normal utility power is restored. Within seconds your power is back online and powering your whole home. You can leave your home knowing it is protected.
Trouble Free
A main circuit breaker protects the generator from overload. Protection for other components is from a set of fuses located behind the panel. Indicator lights illuminate if one has tripped. We do not expect you will ever have any problems but, we still build our generators to be easily serviced.
A main circuit breaker protects the generator from overload. Protection for other components is from a set of fuses located behind the panel. Indicator lights illuminate if one has tripped. We do not expect you will ever have any problems but, we still build our generators to be easily serviced.
