Home > Products > Ungroup 2 > LD6BTseries Watercooled Soundproof 150kw Generator

LD6BTseries Watercooled Soundproof 150kw Generator

FOB Price

US$ 11,000 - 11,500 / Set

1 Set(Min. Order)

Port Shenzhen/Guangzhou
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangxi, China	Brand Name	LD
Model Number	128GF	Output Type	AC Three Phase
Speed	1500r/min	Frequency	50Hz/60Hz
Rated Power	150kw/150kva	Rated Voltage	230/400V
Rated Current	270A

Product Description

Main Product: diesel engine, diesel generator, alternator and spare parts;

Diesel Engine Usage: Widely used for generator set, boat, wheel loader, truck, water pump, sand pump,

fire pump, construction machine, etc;
Diesel Engine Power Range: from 20kw up to 700kw;

Diesel Generator Power Range: from 30kw up to 700kw.

LD6BTseries Watercooled Soundproof 150kw Generator Technical Patameters

Genset Model (LD Brand)		LD150GF
Rated Power/Speed (kw/r/min)		150/1500

LD Diesel Engine	Engine Model	LD6CTA8.3-G1
	Rated Power/Speed kw/r/min	163/1500
	Type	Vertical,inline,water-cooled,four stroke
	Intake Way	Turbocharged&intercooled
	Number of cylinders×bore×stroke(mm)	6-114×135
	Total dispalcement(L)	8.3
	Min fuel consumption (g/kw.h)	≤195
	Starting type	Electric
	Speed governor model	Mechanical
	Oil capacity(L)	20~22
	Low noise limit dB(A)	98

Wattek Alternator (Stamford Technology)	Alternator nodel	274G
	Rated voltage(V)	400/230 or 380/220
	Current(A)	270
	Freq(Hz)	50 or 60
	Regulator approach	AVR
	Power factor(CosØ)	0.8 Lagging
	Phase	3Phase 4Wire
	Insulation Class	F/H
	Protection Class	IP22/IP23

Genset Packing	Net weight(kg)	2200
Genset Packing	Genset dimension LWH(mm)	3300×1150×1500

More Diesel Generator Models for Option:

Gen-set Model	3-PHASE, 4-WIRE		Model
	Prime Power		Engine	Alternator	Controller
	kw	kva	LD Brand	WATTEK	SMARTGEN
LD22GF	22	27.5	LD4BT3.9-G1	184H	6120
LD40GF	40	50	LD4BTA3.9-G1	224D	6120
LD50GF	50	62.5	LD4BTAA3.9-G2	224E	6120
LD60GF	60	75	LD6BT5.9-G1	224F	6120
LD80GF	80	100	LD6BT5.9-G1	274C	6120
LD100GF	100	125	LD6BT5.9-G1	274D	6120
LD112GF	112	140	LD6BTAA5.9-G1	274E	6120
LD128GF	128	160	LD6CT8.3-G1	274F	6120
LD150GF	150	188	LD6CTA8.3-G2	274G	6120
LD160GF	160	200	LD6CTAA8.3-G2	274H	6120
LD200GF	200	250	LD6LTAA8.9-G2	274K	6120

LD 6BTseries Watercooled Soundproof 150kw Generastor Maintenance Sercvice

1.Warranty interms will be issued by our factory,which is simple and quick;

2.Warranty period will be 12 monthes or 1500 working hours from commissioning date;

3.Parts replacement under warranty will be sent(include sea freight and insurance)to buyers witthout charges;

4.Easy torn parts are excluded in the warrenty,like plugs,condenser,fuse,battery,seal;

5.Problems cased by customer's incorrect man-made operation will be covered by the user;

6.Part use for overhaul and ordinary maintance will be offered by us in factory price;

7.Skillful engineers of us are available dispatched top cuatomers palce for training and service.
