Coal Gangue Ceramsite Production Line with Feature of Enviromental Protection
- Qingdao Tianjin or Shanghai
- T/T
You May Like
-
Petroleum proppant ceramsite pelletizer granulating machine
-
Coal Ash Ceramsite Production Line with Feature of Enviromental Protection
-
Shale Construction Ceramsite Production Line
-
Professional Clay Ceramsite Production Line with Best Rotary Kiln
-
LECA production line and high quality granulating machine
-
Clay Shale Coal ash and Coal gangue Ceramsite Production Line Supply
Product Details
| Place of Origin | China | Brand Name | Songshan | |
| Model Number | Cutomize, LECA production line | Condition | New | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Coal Gangue Ceramsite Production Line:A. light volume
B. high compressive strength
C. low thermal conductivity
D.no radiati
Coal Gangue Ceramsite Production Line with Feature of Enviromental Protection
Simple Introduction of Coal Gangue Ceramsite Production Line :
Lightweight expanded clay aggregate, which is short for LECA production line is mainly used in oil field and the finished product, building materials , gardening , refractory insulation materials, chemical and so on. Ceramic sand is adopted as oil proppant.
LECA consists of small, lightweight, bloated particles of burnt clay. The thousands of small, air-filled cavities give LECA its strength and thermal insulation properties. The base material is plastic clay which is extensively pretreated and then heated and expanded in a rotary kiln. Finally, the product is burned at about 1100°C to form the finished LECA product.
Main Equipment of Coal Gangue Ceramsite Production Line :
The main equipments in Ceramsite Sand Production Line includes hopper, dust-extraction, rotary kiln, Coal injection system, control cabinet, etc. The speed of the feeder under hoper, kiln body and the quantity of coal arching are all of stepless speed regulation.
Auxiliary equipments for shale ceramsite include crusher, screen, belt conveyor, feeder, etc.
Auxiliary equipments for clay and coal ash include double roll mixer, pelletizer, screen, feed, belt conveyor, etc.
Main Ceramsite Type:
2. Coal ash ceramsite
3. Clay ceramsite
4. Shale ceramsite
Production process of Coal Gangue Ceramsite Production Line :
Produce ceramsite generally using the production process of raw material homogenization,granulation, baking, cooling.
According to the type and characteristics of raw materials, Its granulating process can be divided into the following kinds:
1. Plastic method technology: Suitable for clay and clayey material.
Its process: clay - plasticizing - granulating - roasting - cooling - finished products.
2. Mud into the ball process: Suitable for fly ash or other powder raw materials.
Its process: fly ash - mixed smoothing - granulating - roasting - cooling - finished products.
3. Powder grinding ball process: Suitable for shale, clay shale and gangue materials.
Its process: shale - drying - grinding - pre-wetting- granulating - roasting - cooling - finished product.
4. Broken (dry) process: Suitable for shale,etc.
Its process: raw materials and broken graded - roasting shale and finished product. And cooling.
5. Fuel: according to local fuel supply, using bituminous coal, crude oil or natural gas.
Supply Perfect After-Sale Service
We offer a package service-foundation construction, equipment installation, device testing and operation guidance. Whether warranty expires, we will supply timely and thoughtful on-site maintenance.
We give you operation training on customer site to let end-users know how to reduce repair times, prolong usable life of equipment and improve efficiency. Moreover, we will teach end-users to know the structure design, working principle, basic maintenance and fault treatment methods.
We also supply free survey of present equipments conditions and configuration, suggest you one more economic configuration.
