Flotation Machine/flotation Cell for Mineral Flotation Separation
- tianjin qingdao port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Gold Ore Mineral Mining Machinery Gold Mine Flotation Machine Zhongde Brand
-
Gold Mining Beneficiation Mineral Flotation Machine
-
Gold Mining Beneficiation Reseach Mineral Flotation Machine
-
Silver, Gold, Lead Zinc Ore Beneficiation Mineral Flotation Machine by Zhongde
-
Gold Mining Machine, Gold Mining Equipment, Flotation Machine by ZHONGDE
-
China Gold Seperating Machine/Chrome Sand Washing Plant/Gold Mining Equipment With CE Luoyang ZHONGDE
Product Details
| Condition | New | Type | Flotation Separator | |
| Production Capacity | 0.2-0.4t/h | Place of Origin | Henan, China | |
| Brand Name | Zhongde | Model Number | BF-O.37 | |
| Voltage | 380V | Power(W) | 1500 | |
| Dimension(L*W*H) | 0.74*0.74*0.75m | Weight | - | |
| Certification | ISO,BV,CE,TUV certificate,etc. | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.ISO9001:2008 flotation machine2.Big air inlet amount
3.Rational ore pulp circulation
4.Max. effective volume:24
Flotation machine
Characteristics of SF flotation Machine
1. The impeller consists of closed double section cones, which can produce strong down-circulation;
2. Big air inlet amount, low energy consumption;
3. Each trough has the function of air suction, ore pulp suction and flotation, it can make a flotation circuit itself, with no auxiliary equipments. The horizontal configuration makes it easy to change process;
4. Rational ore pulp circulation reduces coarse sand sediment;
5. There are automatic and electric control devices of ore pulp level, which makes easy adjustment.
Technical parameters of flotation machine
| Model | Effective volume (m3) | Inside dimensions(L×W×H)(m) | Air suction amount (m3/m² min) | Power(KW) | Processing capacity(m3/min) |
| SF-0.37 | 0.37 | 0.7×0.7×0.75 | 0.9-1.05 | 1.5 | 470 |
| SF-1.2 | 1.2 | 1.1×1.1×1.1 | 1.0-1.10 | 1.1 | 1370 |
| SF-2.8 | 2.8 | 1.65×1.65×1.15 | 0.9-1.10 | 11 | 2130 |
| SF-4.0 | 4.0 | 1.9×2.0×1.2 | 0.9-1.10 | 15 | 2585 |
| SF-6.0 | 6.0 | 2.2×2.35×1.3 | 0.9-1.10 | 18.5 | 3300 |
| SF-8.0 | 8.0 | 2.25×2.85×1.4 | 0.9-1.10 | 22 30 | 4130 |
| SF-10 | 10 | 2.25×2.85×1.7 | 0.9-1.10 | 22 30 | 4660 |
| SF-16 | 16 | 2.85×3.8×1.7 | 0.9-1.10 | 37 45 | 8320 |
| SF-20 | 20 | 2.85×3.8×2.0 | 0.9-1.10 | 37 45 | 8670 |
| SF-24 | 24 | 3.15×4.15×2.0 | 0.9-1.10 | 45 | 8970
|
Flotation machine pictures
Our services about flotation machine
a. Installation and adjustment: Should the installation service is needed, technicist will be provided by supplier for buyer to assist the work such as welding connection of shell body.
b. Quality Guarantee: Three-guarantees of product and warranty period is one year.
c. Technical support is provided from the beginning to the end.
d. Spare parts are serviced for sale in the whole year
Company Introduction
Luoyang Zhongde Heavy Industries Co., Ltd, whose predecessor was Luoyang Mining Machinery Cement Equipment Factory, was founded in 1959. Over the past fifty years, it has made significant contribution to the economic development in China. In 1995, it took the lead in changing into the joint stock company, which brought rapid development to the company .In 2006, the old factory relocated into the large modern industrial workshop in Luoxin Industrial Park.
took the lead in changing into the joint stock company, which brought rapid development to the company .In 2006, the old factory relocated into the large modern industrial workshop in Luoxin Industrial Park.
Superiority of Zhongde
- World's leading service capability
- The best device management and practice guidances
- Fast, easy and convenient routine maintenance can reduce the downtime
- World's most advanced technology can customize high quality equipment for you
