hydraulic pressure sensor transducer

hydraulic pressure sensor transducer Standard packing(or according to the customer request)

 hydraulic pressure sensor transducer

Basic parameters:

1. Measuring media: oil, water, gas and other compatible media wetted parts
2. Sensor: Stainless diffused silicon sensor
3. Range: 0 ~ 0.7MPa ~ 100MPa; minimum range: 0 ~ 0.5MPa
4. Pressure: 2 times the range (10MPa or less, more may contact)
5.            1.5 times the range (10MPa or more, higher may contact)
6. Accuracy: ± 0.25% FS
7. Non-linear: <± 0.2% FS
8. Hysteresis and repeatability: ≤ ± 0.15% FS
9. Long-term stability: ≤ ± 0.15% FS / year
10. Zero drift: ≤ ± 0.05% FS / ℃
11. Response time: ≤500ms (standard); 200-1000ms adjustable

Electrical parameters:

1. Output: current 2-wire: 4 ~ 20mA;
2. 3-wire voltage: 0 ~ 5V; 0 ~ 10V; 1 ~ 5V; 1 ~ 10V
3. Supply voltage: DC24V (12 ~ 32VDC, less may contact)
4. Load capacity: current output: ≤ 500Ω
5. Voltage output: ≤ 250Ω output impedance
6. Electrical connection: Grommet 2 meters or PG7 He Tasman joints, can be customized to other

Materials:

1. Wetted parts: 316L
2. Shell: 304
3. Seals: Viton, optional: EPOM, NBR
4. Diaphragm: 316L stainless steel

Other specifications:

1. Process connection: G1 / 8, other optional
2. Shell Material: 304
3. Protection class: IP 65 or IP68
4. Medium temperature: -30 ~ 80 ℃
5. Ambient temperature: -40 ~ 80 ℃
6. Storage temperature: -40 ~ 100 ℃
7. Earthquake: 108 RMS (25 ~ 2000HZ)
8. Ex: Ex ia IIC T6 intrinsically safe
9. Current Limit: The maximum current-24mA; voltage-largest 5mA
10. Certification: CE, ISO
11. Installation position: vertical installation is recommended, as there will be other installation extremely slight zero offset

Features:

1. Compact, multiple output
2. Digital ASIC, which greatly improves the accuracy and stability
3. Excellent anti-jamming capability, overvoltage overcurrent protection, reverse polarity protection

Applications:

Widely used in heavy industry, machinery, medical equipment, compressors and other industrial sites, suitable for all compatible with the wetted parts of the media. W series has a variety of process connections, a variety of electrical connections, small size, a variety of output options.
