Anti-corrosion Pressure Sensor All Industrial Manufacturers Price
US$ 40 - 60
/ Piece
1 Piece(Min. Order)
- Any port of China
- T/T L/C D/P D/A Credit Card
You May Like
-
4-20mA Anticorrosive Pressure Sensor Details
-
Electrical Connection Smart Pressure Transmitter Price
-
Pressure Transmitter Hydrochloride (Corrosion-resistant Pressure Transmitter )
-
Anti Corrosive Mini Pressure Transmitter
-
Low Cost Anti-corrosion Type Pressure Sensors
-
Anti-corrosive Digital Pressure Sensor Specification and Introduction
Product Details
| Place of Origin | Shaanxi, China | Brand Name | Yunyi | |
| Model Number | Anticorrosive pressure transmitter |
Standard export package
Product Description
Anti-corrosion pressure sensor All industrial manufacturers price
Description:
Corrosion-resistant ceramic piezoresistive pressure sensor chip, high acid and alkali-resistant high-density polymer materials are corrosion resistant cables, soaked in 37% HCL hydrochloric acid test for two years no anomalies, mainly used for water disinfection with chlorine, chemicals, batteries and other media measurement and control equipment for pressure acid, alkali and other strong corrosive industry, as well as food hygiene, medical and other industries.
Description:
Corrosion-resistant ceramic piezoresistive pressure sensor chip, high acid and alkali-resistant high-density polymer materials are corrosion resistant cables, soaked in 37% HCL hydrochloric acid test for two years no anomalies, mainly used for water disinfection with chlorine, chemicals, batteries and other media measurement and control equipment for pressure acid, alkali and other strong corrosive industry, as well as food hygiene, medical and other industries.
The sensors are usually also known as: corrosion resistance pressure sensors, corrosion-resistant pressure transmitter, the pressure sensor corrosion, corrosion pressure sensor, sulfuric acid pressure sensors, pressure sensors hydrochloric acid, sulfuric acid pressure transmitter, pressure transmitter hydrochloride.
Parameters:
| Measure range | -100KPa~0~10KPa~100Mpa |
| Pressure type | gauge pressure, absolute pressure |
| Power supply | 24VDC, 12VDC |
| Output signal | 4-20mA, 1-5V, 0-5V |
| Temperature compensation | -10~70℃ |
| Working temperature | -20~85℃ |
| Storage temperature | -40~125℃ |
| Zero temperature drift | ±1.5%FS |
| Sensitivity temperature drift | ±1.5%FS |
| Overload | 150%FS |
| Mechanical vibration | 20g(20-5000HZ) |
| Accuracy | ± 0.5%FS ± 0.25%FS |
| Response time | ≤1ms(Up to 90%FS) |
| Load resistance | ≤(U-15)/0.02Ω |
| Material | Stainless steel case; internal 316L sensor |
| Media compatible | Media compatible with 316L stainless steel |
| Protection grade | IP65 |
Company Profile
Xi'an Yunyi Instrument Co., Ltd.
Xian Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer, Mr Tian has more than 30 years experience on this area, and he is one of the engineers who introduced the Rosemount technology. We are specialized in developing pressure transmitter, etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
