Home > Products > Angle steel > ASTM JIS Standard Structural Angle Steel 100x100
ASTM JIS Standard Structural Angle Steel 100x100
- Mainly Xingang China
- T/T
You May Like
Product Details
| Standard | ASTM, BS, DIN, GB, JIS | Grade | Q235B,Q345B,SS400 | |
| Dimensions | 20*20*3--250*250*35 | Place of Origin | Hebei, China | |
| Brand Name | YUNFENG | Model Number | 20*20*3--250*250*35 | |
| Type | Carbon Structural Steel | Application | Buliding Constructions | |
| Shape | Angle |
Product Description
1. Hot Rolled Equal Angle Steel
2. Specifications of Equal Angle Steel
EQUAL ANGLE (kg/m) | |||||
20*3 | 0.889 | 75*8 | 9.03 | 130*13 | 25.4 |
20*4 | 1.145 | 75*10 | 11.089 | 130*14 | 27.2 |
25*2 | 0.763 | 75*9 | 10.06 | 130*16 | 30.9 |
25*4 | 1.459 | 80*5 | 6.211 | 150*10 | 23 |
30*2 | 0.922 | 80*6 | 7.376 | 150*12 | 27.3 |
30*3 | 1.373 | 80*7 | 8.525 | 150*14 | 31.6 |
30*4 | 1.786 | 80*8 | 9.658 | 150*15 | 33.8 |
40*3 | 1.852 | 80*10 | 11.874 | 140*10 | 21.488 |
40*4 | 2.422 | 90*6 | 8.35 | 140*12 | 25.522 |
40*5 | 2.976 | 90*7 | 9.656 | 140*14 | 29.49 |
45*4 | 2.736 | 90*8 | 10.946 | 160*10 | 24.729 |
45*5 | 3.369 | 90*10 | 13.476 | 160*12 | 29.391 |
50*3 | 2.332 | 100*6 | 9.366 | 160*14 | 33.987 |
50*4 | 3.059 | 100*7 | 10.83 | 160*16 | 38.581 |
50*5 | 3.77 | 100*8 | 12.276 | 180*12 | 33.159 |
50*6 | 4.465 | 100*10 | 15.12 | 180*14 | 38.382 |
56*4 | 3.446 | 100*12 | 17.898 | 180*16 | 43.542 |
56*5 | 4.251 | 110*7 | 11.928 | 180*18 | 48.634 |
63*4 | 3.907 | 110*8 | 13.532 | 200*14 | 42.894 |
63*5 | 4.822 | 110*10 | 16.69 | 200*16 | 48.68 |
63*6 | 5.721 | 110*12 | 19.782 | 200*18 | 54.401 |
63*8 | 7.469 | 120*8 | 14.88 | 200*20 | 60.056 |
70*5 | 5.397 | 120*10 | 18.37 | 200*24 | 71.168 |
70*6 | 6.406 | 120*12 | 21.666 | 200*25 | 73.6 |
70*7 | 7.398 | 125*8 | 15.504 | 175*12 | 31.8 |
70*8 | 8.373 | 125*10 | 19.133 | 175*15 | 39.4 |
75*5 | 5.818 | 125*12 | 22.696 | 250*250*25 | 93.77 |
75*6 | 6.905 | 130*10 | 19.8 | 250*250*35 | 128 |
75*7 | 7.976 | 130*12 | 23.6 |
|
|
3. Specifications of Unequal Angle Steel
UNEQUAL ANGLE (kg/m) | |||
125*75*7 | 10.7 | 110*70*7 | 9.656 |
125*75*8 | 12.2 | 110*70*8 | 10.946 |
125*75*9 | 13.6 | 110*70*10 | 13.476 |
125*75*10 | 15 | 125*80*7 | 11.066 |
125*75*12 | 17.8 | 125*80*8 | 12.551 |
150*90*8 | 14.7 | 125*80*10 | 15.474 |
150*90*9 | 16.4 | 125*80*12 | 18.33 |
150*90*10 | 18.2 | 140*90*8 | 14.16 |
150*90*12 | 21.6 | 140*90*10 | 17.475 |
200*100*12 | 27.62 | 140*90*12 | 20.724 |
200*100*15 | 34.04 | 140*90*14 | 23.908 |
45*30*4 | 2.251 | 160*100*10 | 19.872 |
50*32*4 | 2.494 | 160*100*12 | 23.592 |
56*36*4 | 2.818 | 160*100*14 | 25.247 |
56*36*5 | 3.466 | 160*100*16 | 30.835 |
63*40*5 | 3.92 | 180*110*10 | 22.273 |
63*40*6 | 4.638 | 180*110*12 | 26.464 |
75*50*5 | 4.808 | 180*110*14 | 30.589 |
75*50*6 | 5.699 | 180*110*16 | 34.649 |
75*50*8 | 7.431 | 200*125*12 | 29.761 |
90*56*6 | 6.77 | 200*125*14 | 34.436 |
90*56*8 | 8.779 | 200*125*16 | 39.045 |
100*63*6 | 7.55 | 200*125*18 | 43.588 |
100*63*8 | 9.878 | 200*125*20 | 47.885 |
100*63*10 | 12.142 | 100*75*6 | 8.06 |
100*80*6 | 8.35 | 100*75*7 | 9.34 |
100*80*7 | 9.656 | 100*75*8 | 10.6 |
100*80*8 | 10.946 | 100*75*9 | 11.8 |
100*80*10 | 13.476 | 100*75*10 | 13 |
110*70*6 | 8.35 | 100*75*12 | 15.35 |
