Disinctive Design Laboratorial Single Channel Syringe Pumps TJ-3A



Specifications:

• Max. Infusion Distance: 90 mm
• Acceptable Sample Syringe: 5 µL - 60 mL
• Linear Speed: 7.9 µm/min - 79.4 mm/min
• Adjusting Resolution: 7.9 µL/min
• Distance Resolution: 0.165 µm
• Linear Force: > 90 N
• Setting Mode: Membrane keypad and rotary coded switch
• Control Accuracy: < +/- 0.5% in condition of 30% of the full stroke
• Display: 128x64 graphic LCD
• External Control Interface: Start/Stop control, fast forward control, fast reverse control
• Communication Interface: RS485
• Power Supply: AC 100 V - 240 V or DC12V
• Power Consumption: < 10W
• Operating Condition: Temperature 0 to 40°C; relative humidity < 80%
• Controller Dimensions (Lx W x H) : 170 x 108 x 70 (mm)
• Controller Weight: 0.8 Kg
• Drive Unit Dimensions (L x W x H): 245 x 100x 95 (mm)
• Drive Unit Weight: 1.3 Kg

Parameters:

 Feasures:

• User-defined syringe: Storing 4 inner diameters of user-defined syringe
• Linear force output: > 90 N
• Adopt membrane keypad, easy to operate
• Memory function: Storing the running parameters automatically
• Signal outputs: Start/Stop output, cw/ccw output (Open Collector)
• Calibration: Acquire accurate volume through calibration
• Fast forward & fast reverse: Infusion or withdrawal at the max. speed (158.8 mm/min)

Protective Box & Carton
