Product Details
| Place of Origin | Shandong, China | Brand Name | QL | |
| Model Number | NACM 90-G43 | Structure | Welded Chain | |
| Function | Drag Chain | Material | Alloy | |
| Standard or Nonstandard | Standard |
Product Description
G70 NACM90 tow Chain with eye grab chain
1)American standard;
2)strength:G70 grade;
3)length:1/4''--3/8";
4) we are directly factory;
1)Surface treatment: Electro galvanized link chain, hot dipping galvanized link chain, zinc plated (white, blue, yellow, color zinc plating), blackened link chain, self color link chain, black oxide link chain),
2)Standard: Ordinary mild steel link chain, short link chain, medium link chain, long link chain, American Standard link chain (ASTM1980, NACM1990, NACM1996/NACM2003), Germany Standard link chain(DIN5685A/C short/long link chain, DIN763/DIN764, DIN766) Australian Standard, Japan Standard,
| CHAINS WITH CLEVIS/EYE GRAB HOOKS ON BOTH ENDS | ||||||||||
| SIZE | ASTM80 | NACM90 | NACM96/2003 | PC/DRUM | ||||||
| WT | W.L | B.L | WT | W.L | B.L | WT | W.L | B.L | ||
| KG | LB | LB | KG | LB | LB | KG | LB | LB | ||
| GRADE 43 | ||||||||||
| 1/4"×14′ | 5 | 2150 | 7750 | 4.5 | 2600 | 7500 | 4.5 | 2600 | 7800 | 50 |
| 1/4"×16′ | 6 | 2150 | 7750 | 5 | 2600 | 7500 | 5 | 2600 | 7800 | 40 |
| 5/16"×14′ | 7.5 | 3200 | 11600 | 6 | 3900 | 9700 | 7 | 3900 | 11700 | 35 |
| 5/16"×16′ | 8.5 | 3200 | 11600 | 6.5 | 3900 | 9700 | 8 | 3900 | 11700 | 30 |
| 5/16"×18′ | 9.5 | 3200 | 11600 | 7.5 | 3900 | 9700 | 9 | 3900 | 11700 | 30 |
| 5/16"×20′ | 10.5 | 3200 | 11600 | 8 | 3900 | 9700 | 9.5 | 3900 | 11700 | 25 |
| 5/16"×25′ | 13 | 3200 | 11600 | 10 | 3900 | 9700 | 12 | 3900 | 11700 | 20 |
| 5/16"×30′ | 15.5 | 3200 | 11600 | 12 | 3900 | 9700 | 14 | 3900 | 11700 | 20 |
| 3/8"×14′ | 10.5 | 4450 | 16200 | 9.5 | 5400 | 15200 | 10 | 5400 | 16200 | 25 |
| 3/8"×16′ | 12 | 4450 | 16200 | 11 | 5400 | 15200 | 11.5 | 5400 | 16200 | 25 |
| 3/8"×20′ | 15 | 4450 | 16200 | 13.5 | 5400 | 15200 | 13.5 | 5400 | 16200 | 20 |
| 3/8"×25′ | 18.5 | 4450 | 16200 | 16.5 | 5400 | 15200 | 17.5 | 5400 | 16200 | 20 |
| GRADE 70 | ||||||||||
| 1/4"×14′ | 5 | 3150 | 12600 | 4.5 | 3150 | 12100 | 4 | 3150 | 12600 | 50 |
| 1/4"×16′ | 6 | 3150 | 12600 | 5 | 3150 | 12100 | 5 | 3150 | 12600 | 40 |
| 5/16"×14′ | 7.5 | 4700 | 18800 | 7 | 4700 | 18800 | 7 | 4700 | 18800 | 35 |
| 5/16"×16′ | 8.5 | 4700 | 18800 | 8 | 4700 | 18800 | 8 | 4700 | 18800 | 30 |
| 5/16"×18′ | 9.5 | 4700 | 18800 | 8.5 | 4700 | 18800 | 9 | 4700 | 18800 | 30 |
| 5/16"×20′ | 10.5 | 4700 | 18800 | 9 | 4700 | 18800 | 10 | 4700 | 18800 | 25 |
| 5/16"×25′ | 13 | 4700 | 18800 | 10 | 4700 | 18800 | 12 | 4700 | 18800 | 20 |
| 5/16"×30′ | 15.5 | 4700 | 18800 | 12 | 4700 | 18800 | 14.5 | 4700 | 18800 | 20 |
| 3/8"×14′ | 10.5 | 6600 | 26400 | 9.5 | 6600 | 24700 | 10 | 6600 | 26400 | 25 |
| 3/8"×16′ | 12 | 6600 | 26400 | 11 | 6600 | 24700 | 11.5 | 6600 | 26400 | 20 |
| 3/8"×20′ | 15 | 6600 | 26400 | 13.5 | 6600 | 24700 | 14.5 | 6600 | 26400 | 20 |
| 3/8"×25′ | 18.5 | 6600 | 26400 | 16.5 | 6600 | 24700 | 18 | 6600 | 26400 | 15 |
inner packing: plastic bags outside packing:drums+pallet.
or as your inquirements
Shandong province Xintai City Qiangli Chain Co., Ltd was founded in 1998, has nearly 20 years of history. The registered capital 5 billion, is a professional company of production and sales cirque chain .
Our Company has strong technological power, complete testing equipment,and the domestic advanced level of chain design development and process control means. Products are widely used in coal mine, cement, metallurgy, hoisting, ship, boiler slag, greening and other industries.
