New Arrival Sony IMX178 Chipset Onvif 5mp ip Security Cctv Camera Poe
- shenzhen
- T/T Credit Card PayPal
You May Like
-
New Products Sony Sensor H.265 5mp Array Led hd ip Camera Poe,camera Rohs Conform
-
3megapixel 2.8 ip Camera Poe Dome Indoor Outdoor Anti-vandal Dome ir Camera
-
New Products 3mp ip Poe Cameras Vari-focal Domes H264 H265 Poe ip External Dome Camera
-
PLV 2mp Outdoor IR-Cut Filter Ip66 Poe ip Camera China Oem ip Camera Manufacturers
-
2mp ir Cut Zoom Poe 1080p Front Door Wall-mounted Survillance ip Camera With ce Rohs
-
New Products 2015 Infrared Waterproof 2.8~12mm Auto Focus Home Guard Security ip Camera
Product Details
| Place of Origin | Guangdong, China | Brand Name | PLV | |
| Model Number | PLV-NC511FE | Type | Digital Camera | |
| Style | Dome Camera | Sensor | CMOS | |
| Technology | Infrared | Special Features | Waterproof / Weatherproof |
Product Description
New arrival Sony IMX178 chipset onvif 5mp ip security cctv camera poe
Key Features:
- 5MP(2592*1944)@25/30fps
- H.265/H.264 High Profile compression algorithm
- 5.5mm 5Megapixel Fixed-Focal Lens
- 1/1.8” Sony IMX178 CMOS Image Sensor
- Day/Night Mode Auto-Switch
- ONVIF
- 30meters IR distance
- IP66 Waterproof Metal Casing
- DC 12V Power Supply
- Dimension: 188mm*88mm*85mm
- Weight: 0.9Kg
Product Pictures:
Why we need 5mp full hd ip camera ?
- We don't just want to see it. We must watch it clearly.
- So we need to upgrade the system from Standard Definition to High Definition
- So we need to upgrad to H.264/H.265 High Profile compression algorithm
- Best choice make things easy
- PLV, Bring You a Clear World, Guard Your Happy Life
Main Parameters:
Camera | |||
Image Device | 1/1.8" Sony IMX178 Progressive CMOS Sensor | Shutter Time | 1/25s~1/100,000s |
Lens | 5.5mm 5MegaPixel Fixed-Focal Lens | Lens Mount | M12 |
Day&Night | ICR | WDR | Digital WDR |
Minimum Illumination | Color:0.01Lux F1.2,B&W:0.001Lux | DNR | 2D/3D DNR |
Auto Iris | - | POE | Optional |
Video | |||
Video Compression | H.265/H.264 | H.264 Profile | High Profile |
Bit Rate | Main Stream:0.1Mbps ~8Mbps Sub-stream:0.1Mbps ~2Mbps | Resolution | Main:5MP/3MP/1080P Sub:D1 |
Frame Rate | 50Hz: 25fps(2592×1944),60Hz: 30fps(2592×1944) | ||
Audio(Optional) | |||
Audio Compression | G.711 | Talk Back | Support |
Network | |||
Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, FTP, UPNP | ||
Alarm Trigger | Motion detection, Video Analysis, Shelter | Onvif Protocol | Support |
Remote Access | CMS, IE, Mobile Phone | 3G Module | Extended by USB interface |
WIFI | Extended by USB interface | WIFI Encryption | - |
Interface | |||
Network Interface | 1 RJ45 10M/100M Ethernet Port | USB Interface | Support(Optional) |
Audio In | 1channel(Optional) | Audio Out | 1channel(Optional) |
Alarm In | 2channel(Optional) | Alarm Out | - |
Storage Interface | 32GB Micro-SD(TF) Card(Optional) | Serial Port | RS-485(Optional) |
General | |||
Operation Temperature | -10℃~ +60℃ | Working Humidity | 0% - 90% |
Water-proof Casing | IP66 | Adapter Requirement | DC12V±10% |
Power Consumption | 5.5W MAX(7.5W When IR turn on) | EXIR range | Up to 30M |
Dimensions(mm) |
| Weight |
|
How does ip camera POE system work?
Typical applications:
Widely applied in Banking, Super Market, Telecommunication, Government, School, Airport, Factory, Hotel, Restaurant, Bus/train Station, Public Square, Building, Store, Office, House and other fields that need HD video surveillance.
How is the shipping and packaging?
1.The package will be shipped from China via Express air or by sea as your request. The tracking number will E-mail to you when the item sent, usually it takes 4~5 working days to arrive by air;it takes 10~45 days to arrive by sea depending on the port.
2.For fast and safe delivery,we can not deliver to P.O. Box number .Please provide physical address and contact phone number.
What service does PLV provide?
We are rich in ODM and OEM experience.
1. Free repair within one year after the shipment of products from us.
2. Replacement within 30 days after the shipment of products from us due to products' problems.
3. We can print your logo and stick your model No.on the cameras.
4. We have long cooperation with many shipping companies and our export volume is large. The shipping companies can offer us good discounts.
5. Professional technician supports. We have a good after-sales service team. They can solve your problems in time.
6.All goods will be inspected and tested before shipment.
7.Customer`s satisfactory is most important to us.If you have any problem or questions regarding our transaction.Please contact us by Trademanager or Email.It will be responded within 24 hours.
The Factory:
The Exhibitons:
MOQ for Products:
1. For the first order, we have no limit for the quantity.
2. From the second order, the MOQ is 60pcs.
Payment Terms
T/T *** Western Union *** PayPal
Lead Time
Sample order : 3~7 working days
Bulk order : 7 - 15 working days.
OEM / ODM Service
Above 60pcs, free customization service to silk-screen print customer’s logo,labels, boxes, etc.
For ODM projects, welcome your enquiries!
Different IP Camera models optional.
Send your inquiry details in the Below for sample. Click “Send” Now!
