Home > Products > Crawler Loader series > Mini track loader, Wanfeng Brand crawler loader
Mini track loader, Wanfeng Brand crawler loader
- Shanghai port qingdao port
- T/T
You May Like
-
Bucket loader crawler loaders for underground mine
-
High quality grilled slag machine made in china
-
High quality grilled slag machine used in coal mine
-
Crawler loader, WZT, Slag-raking machine, Aluminum cinder scraper made in china
-
Crawler Loader small type tracked mining loader
-
Crawler Mucking Loader for underground mine
Product Details
Place of Origin | Henan, China | Brand Name | Wanfeng | |
Condition | New | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
cralwer loader
Product name: mini track loader, Wanfeng Brand crawler loader
Item | Unit | Technical Parameter | |||
Model No. |
| ZWY-100/45L | ZWY-80/45L | ZWY-60/30L | |
Machine weight | Kg | 12200 | 11860 | 6800 | |
Loading capacity | M³/h | 100 | 80 | 60 | |
|
| reach boom broken boom(Optional) | reach boom broken boom(Optional) |
| |
Digging width | mm | 5300 4800 | 4800 3200 | 3200 | |
Digging distance | mm | 1970 1820 | 1820 1530 | 1530 | |
Digging height | mm | 3090 2570 | 2570 2300 | 2300 | |
Digging depth | mm | 600 480 | 480 320 | 320 | |
Dumping height | mm | 1480~1760(variable) | 1470~1646(variable) | 1350(variable) | |
Dumping distance | mm | 1700(variable) | 1600(variable) | 1500(variable) | |
Driving speed | m/s | 0.25±5% | 0.25±5% | 0.25±5% | |
Speed of scraper chain | m/min | 40 | 40 | 34 | |
Scraper chain transportation organization form |
| single chain single drive | single chain single drive | single chain single drive | |
Applicable roadway slope | (°) | ≤32 | ≤32 | ≤32 | |
Maximum working pressure | Mpa | ≤32 | ≤32 | ≤32 | |
Ground pressure | Mpa | ≤0.1 | ≤0.1 | ≤0.087 | |
Ground clearance | mm | ≤310(can be heighten) | ≤310(can be heighten) | ≤320(can be heighten) | |
Total Power | Kw | 45 | 45 | 30 | |
Operation manner |
| Hydraulic control | Hydraulic control | Hydraulic control | |
Conveyor inner width | mm | 941(can be widen) | 941(can be widen) | 900(can be widen) | |
Maximum material go through size(W×H) | mm | 580×710 | 580×710 | 480×520 | |
Working arm maximum turning angle | (°) | ±55 | ±55 | ±55 | |
Dimension(transport position) | Length | mm | 8100 | 7710 | 6030 |
width | mm | 1690 | 1690 | 1500 | |
height | mm | 2100 | 1990 | 1800 | |
Dimension(working position) | length | mm | 9700 | 9222 | 6500 |
width | mm | 1690 | 1690 | 1500 | |
height | mm | 2310 | 2247 | 1900 | |
adaptive tunnel dimension(W×H) | m | ≥2.5×2.5 | ≥2.4×2.4 | ≥2×2 |
