Pet Plastic Bottle Making Machine Price
- shanghai
- T/T
You May Like
Product Details
| Condition | New | Application | Other, bottle,drum,jerry can,bumper,spoiler,water tank | |
| Plastic Processed | Other, PE , PP,PVC,PC,PA,ABS,PETG,TPU,EVOH,TPE,PPE etc. | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | Yes | Place of Origin | Jiangsu, China | |
| Brand Name | longhua | Model Number | LHB45D | |
| Voltage | 220V 315V 380V 450V | Power(W) | 4kw | |
| Dimension(L*W*H) | 2.6*1.4*2.2 | Weight | 2.8ton | |
| Certification | CE,ISO9001 | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
pet plastic bottle making machine pricea.fully automatic
b.hydraulic controlling
c.energy saving
d.easy operating
LHB45D plastic extrusion fully automatic blow moulding machine was specially designed for making plastic water bottles,medical bottles,oil bottles,plastic balls ,suction tubes and other small plastic containers not over 1.5L.
pet plastic bottle making machine price
Products produced by our machine
Main parts of Machine | Picture | Explanation |
Mould Open and Close machanism |
|
Single station Open and close the mould |
Oil Pump |
| Oil pump From TaiWan JinShun use to drive the machine |
Computer control system (PLC) | | Japanese Mitisubishi PLC
Used to control all electrial components and touch screen |
Screw and fan |
|
Screw diemeter 45mm Fan used to cool the screw. |
Die head | |
Double die heads available More fast and reliable output |
Electric Cabinet |
| This part is the full electric components of the machine |
Our Achievements
The main components of the machine. ( LHB45D )
electronic parts |
|
Name | Trader |
Micro computer control system | Japanese MITSUBISHI |
Temperature Controller | TAIWAN HONGGE PID |
Auxiliary Relay | OMRON |
contactor | Schneider from France |
Electric motor | Three phase 220V or 380V |
Power Source | TAIWAN MEANWELL |
Transducer | CHINSC Japan |
hydraulic parts |
|
Name | Trader |
Oil pump | TAIWAN HIGH-TECH |
Valve | AIRTAC/TAIWAN |
Oil pump and connection | TAIWAN |
Sealed part | HALLITE |
air control system |
|
Name | Trader |
Cylinder | AIRTAC |
Air Valve | AIRTAC |
Technical Parameters: ( LHB45D )
Max. Product volume | 1.5L |
Out put capacity | 500~600pcs/h |
Screw diameter | 45mm |
Screw L/D ratio | 24:1 L/D |
Screw drive power | 10 KW |
Screw heating capacity | 2.6 KW |
No.of heating zone | 3 zones |
Output of HDPE | 35 KG/H |
Oil pump drive power | 4.8 KW |
Clamping force | 32KN |
Max.size of mold | 80-350mm |
Mold stroke | 250 X 320mm |
Max.die diameter | 80mm |
Blowing pressure | 0.6 mpa |
Air Volume | 0.4M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 30 L/MIN |
Size of Machine | 2.6x1.4x2.2m |
Weight of machine | 2.8 ton |
Hope we could have more chances to discuss the more details about the machine you want.
Also you will be very welcomed to visit us at any time.
