Low Cost galvanized steel pipe for greenhouse frame

FOB Price

USD $800 - $3,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Other, Single and multi-tunnel Greenhouse
Cover Material	Film	Material	PE
Layer	Other, Triple	Model Number	OEM
Place of Origin	Anhui, China	Brand Name	OEM

Description:	Tunnel Greenhouse
Size:	According to client's ground size
Material of structure:	Galvanized Steel Pipe 15 years warranty
Material of cover:	150mic PE Film, 3 years warrant, 5 years life time
Door:	Leaf door/Slide door
Installation:	Easy to Install, no welding, installation manual is available
Production time:	15-30days
M.O.Q.:	1 set

Framework/Structure

1) The greenhouse is constructed with 32mm hot galvanized steel pipe,

thickness 1.2 mm/1.5mm/2.0mm, anti-rust treated, guarantee for 15 years;

2) Purlin: 25mm diameter

3) Arch space: 1m/2m/0.8m

4) Stable structures with long life time.

The connections of the greenhouse are by claw and clamp, screw, bolts and nuts etc, no welding needed.

The roof and four sides are covered by 0.15mm thickness clear pe film

Type	Thickness	Thick Tolarence	Light Trans-	Diffusion		Anti-impact force	Tensile strength	Extension Rate
3755	0.15mm	±5% (%)	≥88 (%)	30-45 %		500g	23 MPa	550/650 %

Ventilation

1)manual sidewall roll up winches

2)All vents are covered by plastic film and 50 mesh white insect net.

Door

One Sliding door on the front side, galvanized steel frame, covered by plastic film, 2m height x 2m width.
