Product Details
| Place of Origin | Guangdong, China | Brand Name | TWSPCB | |
| Model Number | Double Sided PCB | Base Material | FR-4 | |
| Copper Thickness | Hoz 1oz 2oz 3oz | Board Thickness | 0.4mm-3.2mm | |
| Min. Hole Size | 0.20mm | Min. Line Width | 0.1mm(4mil) | |
| Min. Line Spacing | 0.1mm(4mil) | Surface Finishing | OSP/HASL/LF HASL/ENIG/ENIT/ENIS |
Product Description
Fast Double-sided Heatbed MK2 PCB Manufacturer in China
Welcome to TianWeiSheng!
Item | Single board ,multilayer board, flexible board | multilayer board ,High density multilayer board ,rigid-flex printed circuit board (More than four layers flexible board) |
Layer | 1-2 layer (flex board)2-8 layer ) | 1-8 layer(flex board),2-16layer((rigid-flex) |
Finish board size(Max) | 250×650mm | 250×650mm |
Board Thickness | 0.0765mm-0.6mm | 0.0765mm-0.6mm |
Min.Trace Width & Line Spacing | 0.05mm/0.05mm(1/3OZCopper foil) | 0.05mm/0.05mm(1/3OZCopper foil) |
Board Thickness tolerance | ±0.05mm | ±0.05mm |
Insulating layer Thickness | 12.5-50um | 12.5um or < 50um |
PTH Hole Dia.Tolerance | ≥0.1mm | ≥0.1mm |
Min.Hole Diameter for CNC Driling | 0.2mm | 0.2mm |
Min.Hole Diameter for punching | 0.1mm | 0.1mm |
Min half Round hole aperture | Φ=0.3MM | Φ=0.3MM |
Hole Tolerance(Crossing hole) | ±0.075mm | ±0.075mm |
Drilling hole Tolerance(not Crossing) | ±0.05mm | ±0.05mm |
Hole Positon | ±0.1mm | ±0.1mm |
Outline Tolerance | ±0.05mm | ±0.05mm |
Immersion Gold | Gold Thickness:0.025um-0.125um Tin Thickness:1um-4um | Gold Thickness:0.025um-0.125um Tin Thickness:1um-4um |
Electrical Nickel-gold | Gold Thickness:0.025um-0.125um Tin Thickness:1um-5um | Gold Thickness:0.025um-0.125um Tin Thickness:1um-5um |
Immersion Tin | Sn:0.025um-0.125um | Sn:0.025um-0.125um |
Anti-Tarnish(OSP) | 0.1um-0.5um | 0.1um-0.5um |
HASH | 1-40um | 1-40um |
Lead tin | 1-40um | 1-40um |
Immersion Ag | ≥1.5um | ≥1.5um |
Thermosetting white oil overprint Tolerance | ±0.2mm | ±0.2mm |
Min width green oil | 0.125mm | 0.125mm |
Min width thermosetting white oil | 0.4mm | 0.4mm |
impedance control | ±100% | ±100% |
Heat shock test | 260±5°C/10S/3T/No stratification | 260±5°C/10S/3T/No stratification |
solderability test | 260±5°C/3-5S/semi-humid≤3% | 260±5°C/3-5S/semi-humid≤3% |
Finished peeling strength | ≥0.8KG/CM | ≥0.8KG/CM |
pollution test | ≤3ug/inch2 | ≤3ug/inch2 |
Finished aging | 72H,70°C | 72H,70°C |
Product standard | Factory mark:GB;IPC-3012;IPC-6013Ⅱ IPC-6013Ⅲ;Army mark;other | Factory mark:GB;IPC-3012;IPC-6013Ⅱ IPC-6013Ⅲ;Army mark;other |
safety certification | UI794:other | UI794:other |
certification of environmental protection | ROSH;SGS6 test report;REACH 38 term test report | ROSH;SGS6 test report;REACH 38 term |
Packaging Details: Vacuum package with carton box
Delivery Detail: 6-10 working days
Shipping:
We usually ship by DHL, FEDEX, UPS, TNT, also we can ship by clients' requirements.
PCB Board Manufacture and PCBA Service:
---PCB board made, circuit board parts purchased by us
---Electronic testing circuit board or PCBA
---Fast delivery, anti-static package
---RoHS Directive-compliant, lead-free
---Components purchasing, PCB assembly, test, packing and PCB delivery
---Eleectronic manufacturing service
Detailed Terms for Pcb Assembly
Technical requirement for pcb&pcb assembly:
---- Professional Surface-mounting and Through-hole soldering Technology
---- Various sizes like 1206,0805,0603 components SMT technology
----ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
----PCB Assembly With UL,CE,FCC,Rohs Approval
----Nitrogen gas reflow soldering technology for SMT.
----High Standard SMT&Solder Assembly Line
---- High density interconnected board placement technology capacity.
Quote requirement for pcb&pcb assembly:
----Gerber file and Bom list
----Clear pics of pcba or pcba sample for us
----Test method for PCBA
A Pioneer in the PCB industry
Shenzhen Tianweisheng Electronic Co., Ltd. started from 1998 and is located in Shenzhen. We have a general investment of RMB 1,000,000 and a plant area of more than 50,000 square meters.
Shenzhen Tianweisheng Electronic Co., Ltd. has abundant financial resources and advanced equipment, including Automatic electroplating production lines, Automatic Horizontal Lines and Lead-Free HAL lines.
As a professional PCB supplier, we have excellent teams which focus on product development & design, quality control & inspection and company management. In order to supply the best products and services, we have built a modern quality management system which is in strict accordance with international standards. Besides, because of large overseas markets, our products have passed UL, ISO9001 and IS014001 certifications. If you have any new idea or concept for the products, please contact us. We are glad to work together with you and finally provide you with satisfactory products.
