NSK 45TAC75B ball screw support bearing

High precision angular contact thrust ball bearings to support precision ball screws, have better performance than earlier combinations of angular contact ball bearings or combinations using thrust bearings. they are especially suitable for high precision machine-tool feeding mechanisms and similar applications.
TAC B series
The axial rigidity is high because of a large number of balls and a contact angle of 60°.compared with tapered roller bearings of cylindrial roller bearings, this type has lower starting torque; so smoother rotation is possible with less driving force.
TAC B series bearings incorporate NSK's recently developed molded polyamide resin cage. In additon using extra-pure steel for the inner and outer rings has further enhanced service life. our EP steel is manufactured by controlling the amount of harmful oxide inclusions , which eliminates large size inclusions and enjoys higher purity than vaccum arc remelted(var) steel.
The series with "DG" seal, low torque contact seal, with "WPH" grease, an waterproof grease, increase the reliability and provide for easy handling.

1. For small ones:anti-rust oil+vacuum plastic bag+paper box+wooden box

2. For big ones:anti-rust oil+waterproof belt+professional belt+wooden box

Payment Terms:

L/C ,T/T ,western Union

1. 30% deposit By T/T, Western Union, Paypal, 70% before delivery.

2. 100% L/C at sight

Other information:

Production Lead time: 7~25days; If we have this item in stock , 2days delivery.

Delivery Date: within 3-5days after your payment.

Sample: Free, but we don't bear the freight of sample

MOQ: 1 set Supply Ablility:100000 pcs/Month

    Professional production team, production line, experienced technical experts who engaged in this industry for more than 10 years. We have the professional production line for this bearings:

• 1. Our bearings are made of Chrome Steel, it have better corrosion resistance, hardenability and toughness.
• 2. Double Seal: Adopt nature rubber, make it hard for dirt and grime to get in, running more quietly.
• 3. Cage: Also made of Chrome Steel, it is more durable than Carbon Steel bearings.
• 4. Capacity: 500000 PCS/MONTH
