HX-230/4Line Automatic N-fold Hand Towel Folding Paper Machine

Specifications

HX-230/4Line automatic N-fold hand towel folding paper machine, N fold paper towel making machine. Hand towel machine.

1.one set of steel to steel style embosser,

2. Adopt new technology of vacuum suction
3.When the paper breaks, the machine stops automatically.

4.Adopt synchronous driving belt transmission,and transmission ratio is accurate

with low noise.

5.PLC is Delta, the brand of frequency converter is LG
6.With Roots vacuum pump

7.It has electrostatic eliminating function.

 Main Characteristic

1. Steel to steel embossing or steel to woolen embossing according to the practical

 need, pneumatically press.

The design is available to customer's requirement.

2. Transmitted by Synchronous belt. The transmitting speed is correct, and the

 noise is low.

3. It cut paper pneumatically. When machine stopes, the cutting blade can separate from paper automaticlly, which makes it easy to pass paper through machine.

4. PLC control and electronically count. Equipped with front and back point move

switches.

 Main technical parameter

1. Maximum width of jumbo roll :920mm (4 lines' output)

2. Maximum of diameter jumbo roll: Φ1200 mm (Other sizes are available)

3. Unfolded size of finished products (mm):230x230, folded size: 76.7x230mm(Other sizes can be customized)

4. Production speed: 1200-1400 Sheets / min

5. Machine power: 20.5KW(380V, 50HZ, 3phase)

5. Equipment overall size (L×W×H): 3000 X3200X1900 mm

6.Equipment weight:2.2 Tons.
