12 Channel ECG Machine
- Shenzhen
- Credit Card
You May Like
-
2013 Hot Selling ECG 12leads Single Channel Digital Portable Type JPD-E01
-
2013 Hot Selling Large Screen ECG 12leads Single Channel Digital Portable Type JPD-E01-L
-
2013 Hot Selling Digital Portable ECG Monitor 12leads Three Channels JPD-E03
-
2013 Hot Selling Digital Portable ECG Machine 12 Leads Six Channels JPD-E06
-
2013 Hot Selling Digital Portable Rechargeable LCD Screen ECG Machine 12leads 12channels JPD-E12
-
ECG SIX Channel ECG Machine
Product Details
| Type | Other, ECG | Brand Name | Jumper | |
| Model Number | JPD-E12 | Place of Origin | Guangdong, China |
Product Description
Specifications
12 channel, 5.7inch LCD screen,automatic interpretation.Clinic information input.
150 patient data storge, 216mm print paper
12 Channel ECG machine
12 channel, 5.7inch LCD screen, automatic interpretation. Clinic information input. 150 patient data storge, 216 mm printing paper, built-in help and demo function
Features:
- 12 channel digital ECG machine with interpretation
- Simultaneous acquisition of 12-lead ECG signal
- Manual/Auto/Arrhythmia analysis modes
- Real time ECG, 20 patients cases
- Alphabetic keyboard for patient info
- Multiple printing modes
- 320x240 graphic, 5.7 inch LCD
- High resolution thermal printing system
- High resolution digital filter
- Built-in USB or RS232, optional PC-ECG software
- AC/DC power, built-in rechargeable Ni-MH battery
- Light weight, portable, convenient for use
Specification:
Safety standard | IEC60601-1 class I, type CF |
Lead | Standard 12 Leads, Lead change automatically |
Resolution | 12 bit / 1000Hz |
Operation mode | Manual/Auto/Analysis modes |
Filter | AC, EMG filter |
Drift filter | Anti-drift system |
Input circuit | Floating; Protection against Defibrillator effect |
CMRR | >100dB (with filter) |
Input circuit current | <0.1μA |
Input impedance | ≥50ΜΩ |
Calibrating voltage | 1mV±3% |
Frequency response | 0.05Hz~160Hz (IEC) |
Time constant | >3.2seconds |
Noise level | ≤15Vp-p |
Threshold | ≤20μV |
Sensitivity | Auto 2.5, 5, 10, 20, 40mm/mV |
Recording system | High resolution thermal printer |
Paper speed | 25, 50mm/s±3% |
Recording paper | 210/216mmx20m, roll/fold paper |
Power supply | AC: 220V / 110V, 50/60Hz |
LCD display | 320x240 graphic, 5.7 inch LCD |
Dimensions | 285×265×72mm |
Weight | 3.8kg. |
