260 Degree PTFE Heat Shrinkable Insulation Tubing
- shenzhen
- Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | VAST | |
| Model Number | HTFE | Type | Insulator | |
| Material | Composite Polymer | Application | High Temperature | |
| Rated Voltage | 36kv | Tensile Strength | more than 17.3MPa |
it is available according to your requirements
Product Description
Specifications
shrinkable tubing1.260degree operation
2.chemicals resistant,electrical insulation
3. highly flame retardant
4.heat shrink
260 degree PTFE heat shrinkable insulation tubing:
Features/Applications
HTFE is manufactured with polytetrafluoroethylene (PTFE). Specially designed for applications such as in the field of automotive , military and aerospace, HTFE provides excellent high temperature stability, chemicals resistant, extreme electrical insulation and highly flame retardant.
Operating temperature: -65°C to +260°C
Minimum fully recovery temperature: 350°C
Meet: SAE-AMS-DTL-23053/12
Standard color: Clear(natural)
technical data:
Property | Test Method | Typical Data |
Tensile strength | ASTM D 2671 | ≥34.5 MPa |
Elongation at break | ASTM D 2671 | ≥150% |
Specific gravity | ASTM D 792 | 2.30 |
Heat shock | ASTM D 2671 (400°C, 4 hrs) | No cracking or dropping |
Cold bend | ASTM D 2671 (-65°C, 4 hrs) | No cracking |
Flammability | ASTM D 2671 | Self extinguish |
Volume resistance | ASTM D 2671 | ≥1018Ω .cm |
Dielectric strength | ASTM D 2671 | ≥34KV/mm |
Copper corrosion | UL 224 | Pass |
Fluid resistance | SAE-AMS-DTL-23053/12 | Excellent |
Water absorption | ASTM D 570 | 0.1 Max. |
