1000Mbps 20km 1 RJ45 and 2 SC Interface Ethernet Rs485 Converter

FOB Price

US$ 10 - 100 / Piece

1 Piece(Min. Order)

Port Chengdu China
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Sichuan, China		Brand Name	Neton
Model Number	NMC-3632

Product Description

1000Mbps 20km 1 RJ45 and 2 SC interface ethernet rs485 converter

Products Description

Product Discription

The Media Converter complies with IEEE802.3,IEEE802.3u, IEEE802.3x Standards. It is designed to convert data signal between 1000 Base-Tx and 1000 Base-Fx fast Ethernet. The data signal converted by such high performance media converter can be transmitted up to 10,20Km by fiber-optical cable.
The Converter is equipped with two fiber optic connectors (One for transmitting-Tx and another for receiving-Rx), one RJ-45 connector. Six LED indicators are built-in for easy diagnosing and monitoring the status of power, Unshielded Twisted Paired (UTP) Link,
UTP Activity, Fiber Link, Fiber Activity, Full duplex and data rates. It can be configured automatically for Full Duplex or Half Duplex operation.
It is compact, cost-effective, low dissipative, high reliable and stable. It can be used in standalone applications with 220VAC or –48VDC power supply.

Order Information

Type	Data rate(Mbps)	Description	Laser Transmitter	Encapsulation	Supply Voltage
NMC-3631	1000	SM 10Km	1310nm FP Laser Diode	Dual SC & single RJ45	AC 86~260V
NMC-3632	1000	SM 20Km	1310nm FP Laser Diode	Dual SC & single RJ45	AC 86~260V

Product Features

• Meets IEEE802.3u 100Base TX and 100Base FX standards

• Plug-and-Play installation

• Auto-Negotiation for 1000M TP port speed

• High quality and excellent reliability

• Full-duplex 1000Mbps Ethernet operation up to 20Km

• one RJ45 port for installation easily

• 9 diagnostic and monitoring LEDs for the status of power, FX link/ACT, TX link/ACT

• Half-duplex and full-duplex identify automatically

• Stand-alone with external power adapter

Packaging & Shipping

Products Show

1x9 Optic Transceiver Module

Product Series---SFP Transceiver Module

Factory Show

Certifications

FAQ

1.What is the warranty for your 1x9 optical modules?

All our products with strict quality control.1x9 modules have 1 year warranty and 3-5 years for MTBF. Free for maintaining within warranty period. In fact, Our repair rate is almost zero.

2.Do you ship internationally?
Yes.We can ship anywhere you would like.If your order is paid by T/T, and Westem Union we can ship it via our delivery forwarder or on your shipping account number ,to ensure you are getting the best rates and this allows you to handle the export/import taxes.

3.I placed an order,who do i call to get tracking information?
Our colleagues of shipping will send you the tracking information immediately after shipping. You can also get the tracking messages from your sales servicer.

4.How do I know NETON parts are good?
We currently are an approved vendor/a gold supplier for Alibaba. We have a number of testing facilities at our disposal and have on-site counterfeit screening capabilities.Our reputation has been built on providing quality parts and customer service you can count on.

5. What's your best advantage in the optical modules line?

achieve various customized requires is our favourate advantage. Because over 20 excellent technicials act as our strong backers.

6.What's your main products?

Our main products are optical transceiver modules, like 1x9, SFP,XFP.

And we can produce all datarate series of modules from DC~2M, 2M~622M,622M~2.5G to 2.5G~40G,

and all kinds of encapsulations from 1x9, SFP,XFP, SFP+ to PON, GPON,GEPON even copper connector and metal 1x9, and WDM from CWDM to DWDM are acceptable,

and single/double/triple transceiver module,single/double/triple transmitter module, single/double/triple receiver module for your various demands.
