forklift with bale clamp

FOB Price

USD $10,000 - $30,000 / Unit

1 Unit(Min.Order)

Port Tianjin
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Beijing, China
Brand Name	HYUNDAI	Model Number	HB20e
Type	Other, electric forklift	Power Souce	DC Motor
Rated Loading Capacity	2000kg	Max. Lifting Height	3000mm
Min. Lifting Height	2060mm	Fork Length	1070mm
Fork Width	122mm	Overall Dimensions	336012002220mm
Certification	ISO9001	After-sales Service Provided	No overseas service provided

Product Description

1. advanced strong mechanical device
2. high working property
3. expressing high profermance by the optimized control
4. safe switch equipped in the accelerator ensure parking safely, its service lift excess 10million times, having the IP67 protect grade.
5. the electronic affiliated element DCDC converter supply the power making th storage battery consumed more balanced
6. the capacity of battery is more than the same grade products that ensure the battery can be used for a long time after once charger, connect the artificial intelligence systerm thus there will display the remaining power to prevent overdischarge and extend the working lift.
7. adopt world wide famous controller and the feature: high frequency chopped wave type, mute, high efficiency,continuous electricity control, reduce electric arc and the carbon brush fret, tHB20E07 2 ton electric forklift

feature	model			HB20E(07)
	rated loading capacity		kg	2000
	load center		mm	500
	tyre	C= solid tyre, P= pneumatic		Pneumatic
dimension	2 grade mast	max. lifting height	mm	3000
	bracket	ISO standard		2 grade
	fork	HWL	mm	401221070
	fork distance	min.*max.	mm	240*1100
	mast inclination	Forerake/Retroversion	deg	6°/12°
	enternal dimension	full length	mm	3360
		width	mm	1200
		mast min. height	mm	2060
		overhead guard height	mm	2220
	turn radius	min. outside	mm	2000
performance	travel speed	no load	km/h	12
	travel speed	full load	mm/s	340
	max. gradeability	speed 1.6KM/H (full load)	%	18%
	self weight	No load	kg	3920
axle frame	tire	number		2/2
		front		7.00-12-12PR
		rear		18*7-8-14PR
	wheelbase	distance	mm	1420
	Wheel tread	front	mm	960
	Wheel tread	back	mm	980
	Ground clearance	the lowest point	mm	120
	controller type	traction		SEM
	controller type	hydraulic pressure		DC
	battery	Voltage/capacity	V/AH-5	48/650
	battery	control mode		FET
	charger	charging source	VAC	3*380V
	charger	way		microcomputer full-automatic
