Parts assemble container house

Specifications

Specification

1.This is an assembly container house. It’s between removable container houses and ark box container house. It mainly   uses the modular production technology, putting a container modular into standard parts. It can be assembled temporarily on the spot . It has two advantages: One is to accelerate the speed of the installation and remove, and the other is to lower transportation costs.

The container house, which connection with bolt, isn’t enough strong than welded container house, so this kind of container house isn’t suitable for large size production.

The right size is within 6.05(m)*2.43(m)*2.95(m).

This kind of container house has two types:connection with corner pieces       USD3100--5500

                                                               connection without corner pieces   USD2500--3100

2.The technology parameters is as follows:

(1).Top:

The main profiles: galvanized steel (3mm).

Beam of steel: Hot dip galvanized steel (3mm).

Roof: EPS sandwich board (5mm) +insulation cotton(150mm).

(2).Bottom

The main profiles: galvanized steel (3mm)

Beam of steel: hot dip galvanized steel (3mm)

Forklift hole size: 90mm * 250mm * 2050mm

Waterproof layer: insulation cotton (150mm)

Bottom: color steel panel (0.5mm)

Floor: plank (18mm)

The ground: PVC (2mm)

(3).Corner column

The main profiles: steel (4mm)

(4).Wall

 EPS sandwich (60mm)

(5).Door

double steel door

(6).Electricity

philips two pipe fluorescent lamp (2 X 36 W ),

One distribution box and one circuit breaker
