Nice and Low Price Container House

Specifications

Container House Materials:

1.) Base:
- Frame construction: - 3mm Steel Profile; 4 welded (Container) corner castings with dimensions according to ISO norms;
- Frame construction: - Cold rolled welded; 3mm steel profile; 4 welded;
- Floor: - 18 mm plywood, water resistant (V100), free of formaldehyde (E1); 1.5 mm synthetic floor covering, welded seams.
2.) Roof:
- Frame construction: - 3 mm cold rolled, welded steel profiles;
- 4 corner casts, welded in accordance with ISO norms;
- Steel structure Purlins;
- Load bearing Capacity: - 2K N/m2;
- Roof cover: - 0.50 mm thick, galvanized steel sheet;
- Insulation: - 50 mm-100mm mineral wool, EPS or PU slabs.
3.) Corner Posts:
- Profile: - Cold rolled 4.0 mm steel profile;
- Door panel;
- Fitting: - The four corner posts are fitting with the base frame and the roof with Bolts.
4.) Wall Panels:
- Exterior cladding: - Profiled galvanized sheet metal, steel sheet, 0.5 mm;
- Interior cladding: - Profiled galvanized sheet metal, steel sheet, 0.4 mm;
- Insulation: - 50mm-100mm mineral wool, EPS or PU panel;
- Load bearing capacity: - 0.6 Kn/m2.
5.) Painting & Coating:
All steel profiles will be hot-dipped Zinc galvanized (45μm);
Epoxy zinc primer: Min 40 Microns;
Mineral wool coating: Min 50 Microns;
Total coating: D.F.T: Min 90 Microns;
All zinc galvanized sheet metals are PVC overlaid in standard colors;
6) Windows:
PVC window or Aluminum Alloy window;
Sliding or sewing.
7.) Exterior Doors:
Aluminum door, theft proof steel plate door, sandwich PVC door;
Sewing.
