Tractor SH554S

FOB Price

Negotiable / Unit

1 Unit(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Wheel Tractor
By wheel	4WD	Usage	Farm Tractor
Drive Type	Gear Drive	Power(W)	55HP
Certificate	Other, ISO9001	Brand Name	SHUHE
Model Number	SH554	Place of Origin	Shandong, China
After-sales Service Provided	Overseas service center available

Wheel Tractor 55hp, 4WD:
1)with ISO9001;
2)wet disc brakes;
3)planetary end transmission;
4)double action clutches;

Wheel Tractor 55hp, 4WD:

Model	SH 554/SH554
Engine
Engine Power KW/HP	36,8 / 50
Engine Type (Cyl, T/NA)	4 ,Turbo charger /Natural Aspirated
Rated Speed (rpm)	2400
Engine Torque (Nm @ engine rpm)	175~180,1600~1800
Specific Fuel Consumption (L/h)	≤10.9
Emission Regulation availability (Euro I,II,II)	stageⅡ
Cooling type	Water cooling
Engine Displacement(L)	3.168
Air filter type	Oil Bath
Fuel tank capacity (litres)	38
Exhaust pipe (Vertical/Horizontal)	Vertical
Engine starter (kw)	3.7
Alternator (V/w)	14V/500
TRANSMISSION
Type of clutch	Single, Dry
Total gears	8 F + 4R
Synchronized Gearbox (YES/NO)	NO
Min-Max speed	2.65-34 .78F / 3.94-12.1R
Differential lock (limited slip/100% lock)	100% lock
Max Drawbar Pull 2WD/4WD (KN)	13.5/18
Type of rear final drive (PLanetary, cascade),	Planetary/3
PTO
Pto speeds PT(rpm)	540 / 760
PTO speed @ engine speed	540/760,2400
PTO engagement	8XΦ38/6XΦ35/21XΦ35
PTO independent clutch (YES/NO)	NO
PTO shaft splines	6 or 8
HYDRAULIC SYSTEM
Outlets pump type	gear pump
Max pressure (bar)	175
Max pump delivery @ engine rpm(ml/r),(rpm)	16/2000
Outlets valves function (Kick-out, Detent, Float)	Float
TECHNICAL DATA
Overall size 2WD (LxWxH) / mm	3970x1640x2130
Overall size 4WD (LxWxH) / mm	3970x1640x2130
Max height with ROPS	2300
Max height with CABIN / mm	2500
Rear Wheel track 2WD / mm	1200-1500
Front Wheel track 2WD / mm	1200-1500
Front Wheel track 4WD / mm	1300
Rear Wheel track 4WD / mm	1200-1500
