Effective and Cheap Sound Insulation Materials for Cinema
- shanghai
- T/T
You May Like
-
Fireproof and Sound Insulation Material for Recording Room
-
Fireproof Sound Insulation Materials for Cars
-
Sound Insulation Fabric for Wall and Ceiling
-
Types Sound Insulation Fireproof Materials
-
Waterproof Fireproof Sound Insulation Felt for Office Wall and Ceiling
-
China Manufacture Fireproof 3mm Thickness Sound Insulation Pad
Product Details
| Place of Origin | Shanghai, China | Brand Name | dbsound | |
| Model Number | GYZ-07 | Acoustic Panel Type | Other, soundproof |
Product Description
Soundproof felt Made from the well confected of dozens of organic minerals, which are combined with tasteless EDPM that has perfect performance in aging-resistant and corrosion-resistant aspects at a certain ratio, the damp deadening felt is a device with American advanced technology. Its back is put up with a white hush cloth, which is environment-friendly and tasteless. The hush cloth has good resistance effect on low and high frequency sound, and can effectively restrain the transmission of all kinds of vibrations. The materials can be cut out optionally, and be used conveniently. Compared with domestic products, it has the following merits:
1. Good flexibility will not be broken off after snapping;
2. Fireproof function.
This product is widely used in many places that need noise reduction like construction industry, furniture bedroom, factory houses, machine houses, air compressor, multi-functional hall, KTV singing hall, industrial pipes, office rooms, and automobiles.
| product name | Soundproof material For Interior wall and ceilling |
| color | black,the |
| material | composite material(PVC,EPDM rubber and metal powder), the other side is Non woven fabric |
| weight | 6kg/m2 |
| Fireproof | GB B1 |
| sound transmission loss | 29dB(A) |
| eco-friendly | GB E1 |
| model | GYZ-1.2,GYZ-2.0,GYZ-3.0 |
| application | construction industry, furniture bedroom, factory houses, machine houses, air compressor, multi-functional hall, KTV singing hall, industrial pipes, office rooms, and automobiles. |
| model | size | weight | sound transmission loss |
| GYZ-1.2mm | 10m*1m*1.2mm | 2.4kg/m2 | 24 |
| GYZ-2.0mm | 10m*1m*2mm | 4kg/m2 | 27 |
| GYZ-3.0mm | 5m*1m*3mm | 6kg/m2 | 30 |



step1: This paper takes the intermediate sound deadening wall construction between room A and B. The sound deadening structure is made from lightweight steel keel, and the structure of its two sides is plasterboard, deadening felt, and plasterboard.

step2:
A few deadening felts are placed in the connection part of the sky keel and floor ground. In addition, the sealant is applied on the joint part to reduce the rigidity connection with the wall surface.Building lightweight keel structure, the space between keels should be around 60cm.
step3:
the cavity should be full of glass wool. The thickness of the glass wool in the keel should be about 75% of the keel cavity thickness.
step 4:
The plasterboard should be fixed on sky keels with setscrews. The joint between plasterboards should be treated with sealant, and separately treated.
Fix the deadening felt on plasterboards with all-purpose adhesive, on which plasterboard with different thickness should be coated to avoid coincident effect
Then in the other side of the keel, the plasterboard should be installed in the same way according to the deadening request of the wall.
shanghai dbsound acoustics is a technology company who engaged in acoustic design, acoustic material production and construction.we have Thousands of square meters factory,More than 20 employees and several engineers.dbsound is the member of the Chinese Institute of acoustics and the Shanghai Institute of acoustics,as well as A number of patent.
until now,we have accumulated thousounds of private cinema,Theatre,Recording studio and music hall such as 2010 Shanghai World Expo Macao Pavilion,International Superstar Jackie Chan Performing Arts Center Theatre,SIEMENS Shanghai office sound insulation,Tibetan Buddhist King studio and other national key venues.With a solid professional, rich engineering experience and a stable and reliable product quality, perfect after-sales service ,we get the industry's highly competitive brand.
