Aluminum Led Strip Bar Lightbox Led Strip Rigid Bar

FOB Price

US$ 2.4 - 3.2 / Piece

50 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Model Number	DW-M001	Chip Material	InGaN
Emitting Color	Other, warm white/ middle white/ pure white	Luminous Flux(lm)	1500
Power	Other, 15W	Color Rendering Index(Ra)	85
Color Temperature	3000K/ 4000K/ 6000K	Operating Temperature(℃)	-30, 80
Storage Temperature(℃)	-30, 80	Place of Origin	Guangdong, China
Brand Name	Shield King	Certification	CE

aluminum led strip bar lightbox led strip rigid bar

Feature:

Widely application in led channel letter, backlighting, billboard and lightbox in store, subway lighting boxes.
Easily installation.
High brightness with constant current IC.
Long working life reduce the cost the replace the lights.

Led rigid bar data

lightbox led strip bar	Specification
	Brand	Shield King
	Name	led module bar, led rigid bar, led strip bar, lightbox led strip bar
	Model	DW-M001-1085-15W
	Dimension	L1085W20H6mm
	Power	15W( 15pcs*1W)
	LED brand	Osram 3030led
	LED Qty	15pcs
	Input voltage	AC12V / DC24V
	CCT	6000K/ 4000K/ 3000K
	IP Rating	IP67
	Operating Current	150mA
	Viewing angle	178°
	Operating humidity	10%-90%RH
	Material	Aluminum profile
	Working lifespan	50,000 hrs
	Control Propram	Import constant IC from Japan, stable constant current and efficiency
	Feature	1: Our products are adopted original German Osram led, which is characteristic efficiency, stable, durable and eco-friendly. 2: The shell is made from aluminum alloy, perfect sructure and elegant shape. It's solid, corrosion resistance and easily install. 3: Import Japan acrylic backlight lens, lead to high light transmittance, wide viewing angle, meet the requirement of short distant backlighting installtion. 4: The leds are protected by the embedment from top grade waterproof silicone, the IP grade is 67
	Application	1: Advertisement lighting boxes in subway, airport, railway station etc. 2: Indoor & outdoor of signage illuminating in hotels, stores.. 3: Backlighting for the exterior wall of building. 4: Decorating the channel of indoor as Cove lighting

Led rigid bar

led rigid bar usage

Power supply

led rigid bar ship
