KYJ Fire-Resistant Oil / Hydraulic oil cleaning machine( Stainless Steel, Vacuum Evaporation)
- Shanghai..Chongqing...etc
- T/T Credit Card
You May Like
-
KYJ Fire-Resistant Oil / EH System Oil Filtering Machine ( Stainless Steel, Vacuum Evaporation)
-
KYJ Fire-Resistant Oil / EH System Oil Filtration Machine ( Stainless Steel, Vacuum Evaporation)
-
KYJ Fire-Resistant Oil / EH System Oil Maintenance Machine ( Stainless Steel, Vacuum Evaporation)
-
KYJ Fire-Resistant Oil / EH System Oil Solution Machine ( Stainless Steel, Vacuum Evaporation)
-
KYJ Fire-Resistant Oil / EH System Oil Purifier Machine ( Stainless Steel, Vacuum Evaporation)
-
KYJ Fire-Resistant Oil / EH System Oil Purifying Machine ( Stainless Steel, Vacuum Evaporation)
Product Details
| Condition | New | Flow | 10L/min | |
| Working Pressure | ≤0.5Mpa | Place of Origin | Chongqing, China | |
| Brand Name | Yuneng | Model Number | KYJ | |
| Usage | Other, Hydraulic oil cleaning machine | Voltage | 380V, 50Hz,3 phase or follow yours | |
| Power(W) | 10.5kw | Dimension(L*W*H) | 130x90x150cm | |
| Weight | 370kg | Certification | CE, ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Hydraulic oil cleaning machine1. Vauum type
2. Stainless steel material
3. Acid-removal
KYJ Fire-Resistant Oil / Hydraulic oil cleaning machine( Stainless Steel, Vacuum Evaporation)
(also call EH oil purifier)
Hydraulic oil cleaning machine is especially designed for fire-resistant oil with suitable material for vacuum dehydration, particles-removal and acid-reduction.
For customer choice, we also have a simple type to purify fire-resistant oil: KYJ-I high precision oil filtration. It has simple structure with multi-stage filters to remove particles to NAS grade 5. This machine almost could not remove water. It is suitable for customer who cares about cleanness but does not care about water content.
Features:
1. The tank and pipelines where fire-resistant oil going through are all made of stainless steel.
2. Dehydrate by vacuum distillation, water content less than 100ppm.
3. Oil-input and oil-output keep balance by photoelectric switch which is sensitive and accurate to monitor oil level in the tank, stop inputting oil when level marked high and keep inputting oil when low. Therefore, all series of YUNENG brand oil filtration machines never spray oil.
4. We use filters which designed only for fire-resistant oil to remove particles. Cleanness up to NAS grade 5.
5. There is system with absorbent to solve acid problem.
6. After treatment, the important index-resistivity up to ≥ 6 x 109.
Factory & workshop look
To be shipped
Parameter
Item | Parameter | Unit | KYJ-10 | KYJ-20 | KYJ-30 | KYJ-50 | |
Technical Parameter | Flow Rate | L/MIN | 10 | 20 | 30 | 50 | |
Working Vacuity | Mpa | -0.09 | |||||
Working pressure | Mpa | ≤0.5 | |||||
Temperature Range | oC | 45-65 | |||||
Power Supply |
| 50Hz 380V 3-Phase, Wire (or as requested) | |||||
Total Power | KW | 10 | 12 | 13.5 | 33 | ||
Inlet/Outlet Diameter | mm | 32 | 48 | ||||
Size | Length | mm | 1200 | 1200 | 1200 | 1600 | |
Width | mm | 940 | 960 | 1000 | 1200 | ||
Height | mm | 1550 | 1550 | 1600 | 2000 | ||
Weight | Kg | 380 | 400 | 420 | 500 | ||
Oil Treatment Index | Water Content | ppm | ≤50 | ||||
Filtering Accuracy | µm | ≤1 | |||||
Cleanness | NAS | Grade 5 | |||||
Acid Value | Mg KOH/g | ≤0.03 | |||||
Resistivity | .cm | ≥5x109 | |||||
1. Insulation Oil cleaning machine:
ZJA Ultra-high Transformer / Insulation Oil cleaning machine (1000KV, ±800KV, 750KV, ±660KV project) ( 2 stage vacuum)
ZJA High-vacuum Transformer / Insulation Oil cleaning machine (110KV-500KV project)) (2 stage vacuum)
ZJB Transformer / Insulation Oil cleaning machine (≤110KV) (one stage vacuum)
ZJ Vacuum Pumping machine (extract vacuum, dry transformer)
GF Dry Air Generator (produce dry air for operators to maintain transformer, reactors…).
JZ OLTC (on-load tap changer) online Oil cleaning machine
Quantitative oil injection machine (customized product)
2. Turbine Oil cleaning machine:
JT coalescing dehydration oil cleaning machine (dehydration by special filters)
DYJC online turbine oil cleaning machine (dehydration by special filters and vacuum system)
ZJC-T vacuum oil cleaning machine for turbine oil (dehydration by vacuum system)
3. Lubricating Oil cleaning machine:
ZJC-R vacuum Oil cleaning machine for lubricating oil (machinery oil, hydraulic oil, compressor oil, coolant oil, cutting oil..)
ZJC-M Oil cleaning machine for OCS. (oil with high viscosity 22-320cst at 40°C)
4. Other kinds of oil cleaning machine:
KYJ fire-resistance oil cleaning machine (EHC oil)
LY plate-frame pressure oil cleaning machine (simple, paper filtration)
YL mobile oil cleaning machine (simple, cheap)
5. Waste oil regeneration machine (by chemicals or by high temperature distillation)
YNZSY used oil cleaning machine (by chemicals)
YNZSY-LTY used tire oil cleaning machine (by chemicals)
Waste oil distillation machine
