ploly dome membrane switch used in industrial instrument

FOB Price

USD $0.5 - $3 / Piece

100 Pieces(Min.Order)

Supply Ability 5000 Piece / Pieces per Month
Port Dalian
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Liaoning, China	Brand Name	Geeton
Model Number	GMS-113	Application	Other, Industrial Instrument
Keypad Button Material	Other, PET

Product Description

Specifications

Membrane Switch
Material:PC,PET
Thickness:0.1~1.5MM
Adhesive:double sides tape & water-binder
Customers: SANYO, Panasonic

Press Membrane Keyboard

Dalian Geeton Electronics Co., Ltd specializes in producing membrane switch and nameplate, and we have established more than five years’ stable business partnership with Panasonic, TOSHIBA, OMRON, SANYO and other international well-known enterprises.

Tactile membrane switch Performance:

Electronic characteristics
Circuit rating	35V(DC),100mA,1 W
Contact resistance	10Ω-500Ω(According the trace length and materials to confirm)
Insulation resistance	>100MΩ 250V(DC)
Contact bounce	≤5ms
Dielectric withstand	250VRms(50-60Hz 1/ min)
Life expectancy	flat type≥5 million times, tactile type:≥1 million times
Mechanical Properties
Operating pressure	flat type 57-284g(2-10 Oz),tactile type 170-397g (6-14 Oz)
Switch stroke	flat type 0.1 -0.5mm,tactile type 0.6-1.5mm
Environmental parameters
Operating Temperature	-20°C - +80°C
Storage temperature	-40°C - +85°C
Humidity	40°C,90%-95%,240 hours

Tactile Membrane Switch advantages:

Appearance	Beautiful, bright in color
Design	Small size, light weight, thin thickness, various types of products can be designed according to customer requirements.
Feature	Abrasion resistant, Tightness is good, moisture-proof, dust-proof, anti-oil, anti-corrosion and erosion of harmful gases proof, acid and alkali proof, quake proof.
Quality	In-house 100% functionally tested.
Life expectancy	High lifespan, different types of membrane switch is more than 1 million times.
Operation	Easy to operate, intuitive, safe and reliable, Installation and connection convenience.

If you have any problem, welcome to contact me, thanks a lot.
