Tactile Membrane Switch

FOB Price

USD $1 - $3 / Piece

100 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Tactile Membrane Switch
1.Material: Autotex F150
2.Adhesive: 3M seriers
3.OEM&ODM:Accept
4.Certification: ISO9001,RoHS

Tactile Membrane Switch

Dalian Geeton Electronics Co., Ltd specializes in producing membrane switch and nameplate,

and we have established more than five years’ stable business partnership with Panasonic,

TOSHIBA, OMRON, SANYO and other international well-known enterprises.

Membrane Switch Performance:

Components	LED, metal domes, connector and circuit
Electronic characteristics
Circuit rating	35V(DC),100mA,1 W
Contact resistance	10Ω - 500Ω(According the trace length and materials to confirm)
Insulation resistance	>100MΩ 250V(DC)
Contact bounce	≤5ms
Dielectric withstand	250VRms(50 - 60Hz/1 min)
Life expectancy	flat type≥5 million times, tactile type:≥1 million times
Mechanical Properties
Operating pressure	flat type 57-284g (2-10 Oz),tactile type 170-397g (6-14 Oz)
Switch stroke	flat type 0.1 - 0.5mm, tactile type 0.6 - 1.5mm
Environmental parameters
Operating Temperature	-20°C - +80°C
Storage temperature	-40°C - +85°C
Humidity	40°C,90%-95%,240 hours

Membrane Switch Advantages:

Appearance	Modern, multicolor
Design	Small size, light weight, thin thickness
Feature	Abrasion resistant, moisture-proof, dust-proof, water-proof
Quality	100% QC and the test in making process
Life expectancy	High lifespan, different types of membrane switch is more than 1 million times.
Operation	Easy to operate, intuitive, safe and reliable, Installation and connection convenience.

Products Detail Show

Certification

Workshop Pictures

Inspection Instrument

New Products Recommend

We'd like to provide service in screen printing field. So pls do not hesitate to contact me.
