Home > Products > Plastic extrusion line for pipes and profiles > SJSZ Series PVC pipe production line
SJSZ Series PVC pipe production line
- Shanghai port
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Pipe Production Line | |
| Pipe Material | PVC | Application | Other, electric conduit pipe , water pipe | |
| Production Capacity | max. 250kg/h | Place of Origin | Jiangsu, China | |
| Brand Name | Baixiong Klimens | Model Number | SJSZ51/105, SJSZ65/132 | |
| Voltage | 90 ~115 KW | Power(W) | 90 ~115 KW | |
| Dimension(L*W*H) | 24m*3.5m*3.5m | Weight | min 8T | |
| Certification | CE ISO9001 | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
SJSZ Series PVC pipe production line
1. Introduction:
(1) The main machine is SJSZ51/105 or SJSZ65/132 conical double-screw extruder
(2) It avoids a waste condition when one tube is adjusted and the other one is affected.
(3) The diameter of the extruded pipe is from Φ20-Φ63. It can fully use the extruding capacity
of the extruder.
(4) Even if it produces small diameter pipe, it can get great output, too.
2. Technical data:
Pipe range | 16-40mm | 16-63mm |
Extruder | SJZ51/105 | SJZ65/132 |
Extruder power | 18.5kw | 37kw |
Extrusion capacity | 120kg/h | 250kg/h |
Max. Production speed | 2 x 8m/min | 2 x 10m/min |
3. System configuration:
Item | Machine | Quantity |
1 | Spring loader | 1 set |
2 | Conical Twin-Screw Extruder | 1 set |
3 | Double-extrusion die and head and calibrators | complete set |
4 | Double Vacuum Calibration tank | 1 set |
5 | Printer | 2 sets |
6 | Double Hauling & Cutting Machine | 1 set |
7 | Double Pipe stacker | 1 set |
4. Detailed pictures:
Twin-pipe extrusion :
CE:
Our Global Footprint:
Looking forward to your inquiry !
