KDS Series Plastic Vibrosieve , From 9 Years' Gold Supplier !

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	BXKM
Model Number	KDS Series

plastic vibrosieve
1.Diameter of screen surface:600,1000,1500mm
2.Single-and multiple-layer sortin
3.capacity:1T/H,2.5-6T/H

KDS Series plastic Vibrosieve

1.Features:

(1) Applicable to sizing particles and screening power and liquid;

(2) Excellent power generator;

(3) Single-and multiple-layer sorting;

(4) Low blockage of sieve holes;

(5) Easy replacement of the sieve;

(6) No mechanical vibration conduction;

(7) Wide range of materials to be sieved.

2. Specifications

Model	Power		Diameter of sieve(mm)	Dimensions(mm)	NO. of sieve
KDS-300	0.125		200	350×300×737	1
KDS-450	0.37		450	500×500×650	1
KDS-600	-1F	0.55	550	770×770×720	1
	-2F			770×770×820	2
	-3F			770×770×920	3
KDS-800	-1F	0.735	750	900×900×780	1
	-2F			900×900×930	2
	-3F			920×920×1080	3
KDS-1000	-1F	1.47	950	1180×1150×880	1
	-2F			1180×1180×1030	2
	-3F			1180×1180×1170	3
KDS-1200	-1F	1.84	1150	1380×1350×1050	1
	-2F			1380×1350×1220	2
	-3F			1380×1350×1370	3
KDS-1500	-1F	2.2	1450	1800×1800×1120	1
	-2F			1850×1850×1320	2
	-3F			1900×1900×1520	3
KDS-1800	-1F	3.0	1730	1950×1950×1470	1
	-2F			1950×1950×1630	2
	-3F			1950×1950×1790	3
KDS-2000	-1F	4.0	1930	2200×2200×1630	1
	-2F			2200×2200×1800	2
	-3F			2200×2200×1970	3
KDS-2500	-1F	4.0	2430	2700×2700×1880	1
	-2F			2700×2700×2050	2
	-3F			2700×2700×2200	3
Other special size can produce as customized.
