Home > Products > drying equipment > Hot Air Raisin Drying Unit
Hot Air Raisin Drying Unit
- SHANGHAI
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Shanghai, China | |
| Brand Name | GY | Model Number | gy--H400 | |
| Type | Other, dryer | Voltage | 380V.220V | |
| Power(W) | 40kw | Weight | 300kg | |
| Dimension(L*W*H) | 3500x2200x2000 | Certification | ISO | |
| Warranty | 1 YEAR | After-sales Service Provided | Engineers available to service machinery overseas |
WOODEN BOXES
Product Description
Specifications
GY-400 grape dehydration machine for making raisin1. fruit/vegetable/fruit drying machine
2. capacity: 400kg/patch
raisin drying machine,raisin dryer
We supplier the whole line for raisin processing line:
The production line conclude the processing procedures such as the drying, sand filtering, cleaning, spin-drying, air-drying, oiling, roguing, selecting .
The whole equipments are made of stainless steel, it’s healthy and safe.operate conveniently and reduce the cost of time and water.
If you are interested in any of our products,please contact us at any time and tell us your requirements, we will produce the satisfactory products for you.
Air Source Heat Pump Dryer(drying machine)
1.heat pump dryer running cost just as 40% of oil dryer, 50% of coal burning boiler, 30% of electric boiler;
2. Max temp: 80C;3. during drying, the material does not craze,does not distortions, nondiscolouring,never degenerate, non-oxidize, drying completely,with good Rehydration, keep nutrient content;
4. energy saving and enironmental protection;
5. heating drying and cooling drying,also dehumidify all in one;
6.Conventionally, materials are dried either in the field (sun drying) or using high temperature dryers (electric, gas fired, etc.). Successful outdoor drying depends upon good weather and indeterminate weather can render a product worthless. High temperature drying can damage the nutrient content and impart an unpleasant smell to the dried product.
| MODEL | GY10RD | GY06RD | |||
| Suitable for drying chamber | m3 | 30-50 | 20-30 | ||
| Input power | KW | 11.25 | 6.2 | ||
| Heating capacity | KW | 35 | 22 | ||
| Cooling capacity | KW | 25 | 16 | ||
| Dehydration capacity | L/H | 40 | 20 | ||
| Temperature | °C | 60/75 | 60/75 | ||
| Working ambient temperature | °C | -10~45 | -10~45 | ||
| Refrigerant | Mixture type | Mixture type | |||
| Compressor type | Scroll | Scroll | |||
| Compressor brand | Brand | Copeland/Danfoss | Copeland/Danfoss | ||
| Compressor quantity | units | 2 | 1 | ||
| Noise | dB(A) | 60 | 60 | ||
| Power supply | V | 380 | 380 | ||
| Frequency | HZ | 50 | 50 | ||
| Fan motor for drying 1 | Power input | 550W | 1100W | ||
| (1 units) | Wind volume | 5870m3/H | 8513m3/H | ||
| Rotate speed | 1400R/M | 2900R/M | |||
| Fan motor for drying 2 | Power input | 750W | |||
| (1 units) | Wind volume | 4426m3/H | |||
| Rotate speed | 2900R/M | ||||
| Fan motor for exchange air | Power input | 150W | 250W | ||
| (1 units) | Wind volume | 2000m3/H | 2000m3/H | ||
| Rotate speed | 700R/M | 700R/M | |||
| Fan motor for exchange fresh air | Power input | 6W | 6W | ||
| OPEN | Exchange fresh air | Exchange fresh air | |||
| CLOSE | Drying | Drying | |||
| Fan motor for evaporator | Power input | 2*550W | 780W | ||
| (2 units) | Wind volume | 2*6000m3/H | 6000m3/H | ||
| Rotate speed | 2*1410R/M | 1410R/M | |||
| Wind pipe connector size 1 | mm | 400*400 | 400*400 | ||
| (2 supply-air outlet) | |||||
| Wind pipe connector size 2 | mm | 1150*560 | 1150*435 | ||
| (1 supply-air outlet) | |||||
| Dimension(L*W*H) | mm | 2055*1370*1690 | 2170*1490*1300 | ||
| Weight | Net weight | Kg | 480 | 300 | |
| Gross weight | 540 | 350 | |||
