China Bonly T127-2B Lift Guide Rail

China Bonly T127-2B Elevator Guide Rail

A, Product info;-

1.  T127-2B Machined Elevator Guide Rail;

2. Processing method: Machined;

3. Material: Q235;

4. International standards;

(1) ISO7465:2007;

(2) GBT/22562-2008;

(3) JG/T5072.1-1996;

5. Dimension: 127x89x16; ø17 mm;

6.  Weight: Rail 125 kg, fishplate 5 kg;

7. Each set of guide rail including (1) 5m guide rail; (2) 1 fishplate; (3) One set 8 pieces of grade 8.8 bolt, nut washer and spring washer for fishplate; (4) 4 clips, and he standard fasteners;

8. OEM service provided, customers are welcome to cooperate with us to develop new and better designs;

9. Annual output, 600,000.00 metric tons of raw material guide rails; 200,000.00 metric tons of finished guide rails.

B, Main basic diameters;-

1, Machined Elevator Guide Rail

2, Cold Drawn Elevator Guide Rail

3. Hollow Elevatuo Guide Rail

C. Packing and delivery;

1. Mininum Order Quantity 10 pieces;

2. (1) Plastic sheath used to  protect the end of the guide rail; and (2) iron plate, protecting the guide rail. And (3) Textile membrane wrapped on buldles strapped by steel belt.

3. One bundle 100 pieces;

4. Lead time: 7 days upon receiving down payment.

D. Bonly Poduction Process.

Bonly Process of Manufacture under world-class machinery, ONE STOP PRODUCTION FROM STEEL MAKING TO FINISHED GUIDE RAILS;-

(01) Steel Making → (02) Metallographic Analysis → (03) Steel Rolling → (04) Raw Straightening → (05) Cutting → (06) Tensile Testing → (07) Shot Blasting → (08) Rough Straightening → (09) Painting → (10) Laser Marking (optional) → (11) Panning → (12) Fine Straightening → (13) Machining → (14) Greasing & Filming → (15) Packing & Loading.

Bonly Production flow chart;-

Pictures of Bonly production process;-

A view of Bonly workshop;-

E. Bonly Exportation.

In laste year 2014, Bonly exported 566 meric tons monthly to many countries around the world, including USA, Korea, Iraq, Kuwait, Turkey, Greece, India etc.

Bonly Total Annual Sales Volume is around USD 4.53 Million.

Bonly main partners / customers, including ThyssenKrupp, OTIS, SJEC, Toshiba, Schindler, Yungtay, Giant KONE, KONE, Shanghai Hyundai, Johnson etc:

F, Brief introduction of Bonly Elevator Guide Rail.

Zhejiang Bonly Elevator Guide Rail Manufacture was founded in 2009, located in Hangzhou China. Total land area is 7.5 acre, factory area is 200,000 sqm. Equipped with various advance machines, including super planers, CNC planers, automatic machining lines, auto-straightening/twisting machine, Automatic Vision Inspection System (AVIS). Bonly is the most advanced and one of the biggest elevator guide rail manufacturer, in which the annual production capacity  is 200,000 ton of finished elevator guide rail and 600,000 ton of raw material.

G, Some certificates;

ISO-9001:

ISO-14001

OHSAS-18001:

Exportation Certificate:

H, Parameters in more details.

Bonly Main Specs 1, Machined Elevator Guide Rail;-

Bonly Main Specs 1.2, Diagram of Machined Elevator Guide Rail;-

Bonly Chemical and Mechanical Characteristics;-

Bonly Cold Drawn Elevator Guide Rail;-

Boly Fishplate, Machined;-
