Nickel Plated/ Gold Plated 8 Pin Mini Din Connector Male

Specifications

nickel plated/ gold plated 8 pin mini din connector male

Product informations

 Material

1.Shell:Brass

2.OD=10.0mm

3.Size of shell:12*10mm

4.Total Length: 15mm

5.Shell plated:Ni/Au

6.Pin:8(also can choose 3p to 13p)

   Plated:Ni/Au/Silver

   Contact:Brass

7.Assembled type, solder type

Environmental Spec.(have passed below tests)

1. Salt fog test

2. Air reflow soldering test

3. Mechanical Vibration test

4. Adhered Tin test

5. Temperature Cycle test

Usage:

1.Using for connecting component video and audio for cable TV operator

2.Using for Car Audio or Car cable

3.Using for GPS Navigation

4.Car headrest monitors

5.Computer,Mouse, Keyboard,Video,ect.
