One-component Thermosetting Adhesive for Filter

Specifications

            One-component thermosetting adhesive for air filiter

One.Usage

Filter paper applied to internal combustion engines such as bonding and metal end caps. ( Air filter. Diesel filter. Oil filter. Fuel filter, etc.)

 nical performance

1. Appearance of the uniform viscous liquid (color can be changed according to customer requirements)

2. Viscosity: 3.000-50.000 MPa.s

3.Nonvolatile matter content≥ 98%

4.Curing condition 160 °C - 180 °C 12-20min

5. Tensile strength. High-29.5mm wide 22mm 5-fold folded into the 2.5mm deep layer of filter paper, filter paper --- cured pull away from the metal between the cohesive failure strength≥ 200N

6. Valid from the date of the production within 6 months.

7.Oil aging resistance (135 °C × 192h) is not degumming

8.Density: 3 1.5 ± 0.2 g / ml

9. Packaging 35kg.

.

Three.Attentions

A. should be stored in cool place

B. Time required for heating curing and filter size of the layer thickness of baking temperature and heat transfer methods are associated.

C. Viscosity based on user for adjustment.

Four.Use process description

1. Paper core cover degreasing. Rust and dirt, plastic coating uniformity, thickness less than 2mm

2. Users in different equipment and conditions, ,in the production process to conduct testing to determine the temperature to ensure the best adhesion, the temperature is too low to effect.

3.Packing 35 kilogram per barrel ,Feb,18  2011 The price is 298 RBM per

barrel. 8.5 RMB per kilogram.
