Color stone coated steel roof tile making machine
- 20 Set / Sets per Month
- Tianjin new port
- T/T
You May Like
-
Steel Roof Metal Tile Roll Forming Machine With Touch Screen PLC Frequency Control System
-
Hydraulic Corrugated Metal Roof Panel Roll Forming Manufacturing Machine
-
Top Quality Wave Plate Roll Forming Machine Price
-
Aluminum Roofing Rolling Corrugated Iron Sheet Making Machine
-
China Corrugated Sheet Roll Roofing Tile Making Machine
-
Aluminum Iron Roofing Corrugated Steel Sheet Roll Forming Machine
Product Details
Condition | New | Type | Other, Tile Forming Machine, Color stone coated steel roof tile making machine | |
Tile Type | Colored Glaze Steel | Use | Roof | |
Production Capacity | 6 pieces/min | Place of Origin | Hebei, China | |
Brand Name | HC | Model Number | HC828 | |
Power(W) | 130kw | Voltage | 380V | |
Dimension(L*W*H) | 72000X1550X1910mm | Weight | 35T | |
Certification | ISO&CE | Warranty | 1 year | |
After-sales Service Provided | Overseas service center available |
Product Description
Color stone coated steel roof tile making machine
Application
Stone coated sheet is formed by 0.4mm Al-Zn plating panel and color stones
It is modern,environmental and nice appearance.
We developed this stone coated production line based on long time running and improvement It is high-performance,stable, energy-efficient and easy operation.
Color stone coated steel roof tile making machine part
Leveling-Slitting-Cutting Machine
NO | Main Parameter of Leveling-Slitting-Cutting Machine | |
1 | Slitting Strips | 2-5 adjustable |
2 | Feeding material | 1000-1250mm |
3 | Main motor | 3KW |
4 | Cutting | PLC control the length and quantity |
Working Process: Uncoil-Feeding-Leveling-Slitting-Cutting |
Hydraulic Moulding Machine
Shearing Machine Forming Mould
1.Pressure 315T
2.Normal working pressure: 25MPA
3.Max distance from block to working table: 600MM
4.Stock distance: 600MM
5.Working table size: 1800x1200MM
6.Down motion max speed: 120
7.Back motion max speed: 88
8.Working speed: 17
9.Motor: 22KW
Finished Tile Sample
Color stone coated steel roof tile making machine Sand Blast Part
Automatic Bottom Glue Spraying Equipment
1.Closed automatic spraying glue system |
2.Outside Dimension:4000*1350*850mm(L*W*H) |
3.Structure:Channel steel ,welded |
4.Conveying device:Reciprocating chain conveys |
5.Adsorption of dust removal equipment:1 set |
6.Air compressor: 1 set, 7.5kw, air output is 1m³/min |
7.D46 high-pressure airless spraying system 1 set (German technology) |
8.Automatic high-pressure airless spraying gun: 1 set (Japanese technology) |
9.High-pressure airless manual spraying gun:1 set(Japanese technology) |
10.Standard 15M German import high-pressure airless feed tube and it can support the maximum pressure is 20Mpa |
100L stainless charging basket 1 piece |
Automatic Sandblasting Room
1.Outside Dimension :3000*1850*700mm(L*W*H) |
2.Structure:Channel steel ,angle steel ,welded |
3.Transmission:With glue spraying equipment compound chain transmit |
4.Conveying device:Compound chain transmit |
5.Air compressor: 1 set, 18.5kw, air output is 3m³/min |
6.High-pressure sand suction system: 1 set, sand suction is 1T/hour |
7.Sand hopper: 1 set, dimension:550*600*500 |
8.Automatic shaking sand system: one cylinder, the motor with 0.75kw, control: PLC |
First Drying Room
1.Outside Dimension:4000*1350*850mm(L*W*H) |
2.Structure:Channel steel ,welded |
3.Conveying device:Reciprocating chain conveys |
4.Adsorption of dust removal equipment:1 set |
5.Air compressor: 1 set, 7.5kw, air output is 1m³/min |
6.D46 high-pressure airless spraying system 1 set |
7.Automatic high-pressure airless spraying gun: 1 set |
8.High-pressure airless manual spraying gun:1 set |
9.Standard 15M German import high-pressure airless feed tube and it can support the maximum pressure is 20Mpa |
10.100L stainless charging basket 1 piece |
Automatic Surface Glue Spraying Equipment
1.Outside Dimension :30000*850*700mm(L*W*H) |
2.Structure:carbon steel welded |
3.Frame insulation wall: 30 meters’ long, 1mm carbon steel plate bending forming filled with cotton insulation |
4.Automatic temperature controller:2 sets,Range of adjustable temperature:0-160° |
5.Infrared fluorescent tube:50 pieces |
6.Conveying device: Reciprocating chain conveys 30m |
7.Cooling device:1 set |
8.Total equipment matches total control station 2 sets (Control system) |
9.Productivity:3-6m/min Calculate as 1.2m per piece,eight hours,produce 1500pcs every day |
10.Whole machine power:130kw |
Packaging &Shipping
1.Main Color stone coated steel roof tile making machine and un-coiler is maked (If you need, we can also packed it with water-proof plastic)
2. PLC control system and motor pump are packed with water proof paper,spare parts in carton box.
3.One set of machine needs a 40'container to shipping.
Payment Terms
30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Your payment terms are acceptable.
Delivery Time
Within 30-45 days after receiving deposit
