12 Volt Electric Motor Linear Actuator for Automatic Window Opener

  12 volt electric linear actuator for automatic window opener

The FY Seires linear actuators are widely used in electric sofas, massage chairs, dental chairs, electric medical beds, medical traction bed, television movements counters, furniture and other movements.

Specifications of FY017 Linear Actuator

Name: Linear Actuator
Model: FY017
*Designed for use with torque arm system
*Compact size
*Safe, low voltage operator, 24v or 12V

Specifications:
       1) Voltage: 24VDC or 12VDC
      2) Capacity: 250N /500N/750N/1500N
      3) Max Speed: 40mm/s
      4) Stroke: 50mm ~ 600mm
      5)Type of duty: 10% or 2 minutes continuous use followed

         by 18 minutes not in use
      6) Protection class: IP65,waterproof
      7) Built-in limit switches, not adjustable after leave factory
      8) Certification: CE, RoHS


Features :

     1) Powder Coated Steel Outer Tube

   2) Lubrication for life time

   3) Aluminum extension and outer tubes
   4) Enhanced Corrosion Resistance
   5) Powder Coated Aluminum Alloy Housing

Usage: Electric window, skylight, etc.

Colour: White / Gray / Silver

pictures for 12 volt electric linear actuator for automatic window opener

Installation Dimension of FY017   12 volt electric linear actuator for automatic window opener

More other FY Series Linear Actuator from JDR Company:

 More products of our company

certificates of   12 volt electric linear actuator for automatic window opener

connection for linear actuator with control box and handset

applying pictures for   12 volt electric linear actuator for automatic window opener

pictures for product line and packing

Linear Actuator Connection With Control Box and Handset:
