Good quality All stiainless steel high accuracy digital pressure gauge price

All stiainless steel high accuracy digital pressure gauge price

The gauge adopts the latest advanced micro power consumption intelligent instrument, the standby lithium battery is built-in, which could work 5 to 8 years continuously, and the Big LCD display window is Very eye-catching. The gauge is suitable for all industries and laboratories.

Features

1.11 Units of Calibration, Free to switch

2.Sampling Speed(0.3~20)sec/time, Free to set

3.RS485.RS232 communication and 4~20mA.1~5V output,

4.Many functions such as ntrol.wireless and so on;

5.Big LCD display window, 6 digits, percentage bar ograph of pressure

6.Signal isolation technique, Anti electromagnetic interference and  radio-frequency interference technology

7.Zero point homeostasis technology, Temperature compensation technology

8.Over range protection : Gauge should be fully protected

Unit  Pa. kPa. MPa. Psi. Bar. Mbar. kgf/cm2. kgf/ m2. In H2O,mmH2O, in Hg.mmHg. lbf/ft2

Measuring Range

Gauge Pressure: -100~0~1kPa~ 260MPa

Differential Pressure: 0 ~ 500Pa ~ 3.5MPa                                                                                  Absolute Pressure: 0~10kPa~60MPa

Accuracy Grade

0.05% .0.1%.0.2%.0.5%

Display Mode

5 digits display for accuracy 0.1%, 0.2%, and 0.5%

6 digits display for accuracy 0.05%

Power Supply

Basic type: 3.6 v lithium battery with high-performance

Optional 4.1 v Rechargeable battery

Optional 10~30VDC

Optional Built-in lithium battery +10~30VDC

Sampling Speed

Basic Type: (0.3~20)times/s

High speed type:(0.05~100)times/s

Peak type: >150  times/s

Work time of battery

3.6 v lithium battery with high-performance

4.1 v Rechargeable batteries can be used for 1000 hours for one charge if the sampling Speed is 1 s/time.

Working Conditions

Temperature: -30℃~70 ℃;

Humidity: < 90%Temperature: 0℃~50 ℃ (temperature for Grade 0.05);    Humidity: < 90%Calibration reference condition: 20℃±2℃

About medium temperature

Temperature:(80~120)℃,need Condenser pipe

Temperature:(120~150)℃,need special sensor and Condenser pipe

Protection: IP65

Explosive-proof Grade: ExiaIICT6 (NODE:CNEx11.0116)

Real-time data display,Automatic recording,drawing Pressure curve automatically,the Pressure curve can be exported to Excel, easily.

Process Connection

M20×1.5.M14×1.5.M14×1.M10×1 and so on

G1/2.G3/4.G1/8.G3/8.NPT 1/2.NPT 1/4.NPT 3/8 and so on

Installation

Radial direction type, axial direction type, split and panel mounting type

Package:

More models

pressure sensors,

pressure transmitters,

temperature sensors,

temperature transmitters,

flow meters,

Liquid level instruments,

Calibration equipments,

digital pressure gages etc.

They are widely used in following industries:aerospace, automobilepetroleum, chemical,metallurgy,

Paper-making, drugs manufacturing, electricpower,food, medicine, railroad and water conservationetc.

any inquiry, contact us freely.
