Specifications

Features

             • Compatibility: compatible with HD-SDI and SD-SDI signal

           • Transmission Distance: 0-200m (HD-SDI 1.485Gbps)

           • Characteristics: Automatically clock recovery

             caching processing technology.

           • In conjunction with multiple repeaters, the distance can up to 1km max.

           • Automatically fit the SMPTE and ITU digital video standard.

           • High interference suppression, anti-surge technology

           • Support high-definition HD-SDI digital video at 720p60, 1080i60

             and 1080p30 formats at all frame rates.

           • Integrated cable equalizer for long distance video

             transmission without quality loss.

           • High-quality digital video and audio transmission with nearly zero latency.

Overview

The FS-HD8200V is an active high definition digital signal extender solution for HD-SDI links, operating with 75-5 coaxial cable. Each unit can receive a HD-SDI high definition digital signal that may be attenuated by up to 200m of coaxial cable. The repeater contains three critical components to correct and then retransmit the signal: Adaptive Equalizer to return the signal to its original amplitude and modulation; Reclocker to resynchronize the signal-bringing it back to its original condition; Cable Driver to retransmit the signal with its original characteristics restored. It can use withmultiple repeaters application to extend distance to 1km max. It can be widely used in SDI signal transmission range, such as Security Monitoring System, Television, Digital signal, large conference etc.         .

The FS-HD8200V has super high ability to resist interference and meanwhile, it produces lower radiation to the out side. So it can be used both in the circumstances with some interference and have the request of lower radiation.

Applications

• Security Monitoring System

• Multimedia Network Teaching System

• Medical Monitoring Display System

• Industrial Automation Control System

• Banking, securities, financial information display system

• Remote Network Server Monitoring

• Department Store Security

• Casino Security

• Hospitals, Airports and banks

• School

Technical Specifications

   Application Diagram
