Home > Products > Liquid Filling Machine > 50ml-250L Automatic cooking oil filling machines
50ml-250L Automatic cooking oil filling machines
US$ 2,000 - 40,000
/ Set
1 Set(Min. Order)
- SHANGHAI
- T/T
You May Like
-
20ml-250L(20-100ml,50-500ml,100-1000ml,1-5L,5-30L,50-250L) Automatic cooking oil fillling machine
-
1L- 250L(1-5L,5-30L,50-250L) Automatic bucket oil filling machine
-
100-1000ml automatic bottle lotion filling machine made in china
-
CCG-6 Automatic Injection Filling Machine
-
CDP-24S (Double Rows) In-line Liquid Filling Machine
-
CDP-1W-250L Weighing Filling Machine
Product Details
| Condition | New | Application | Food | |
| Packaging Type | Barrel | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 220v | Power | 1-4KW | |
| Place of Origin | Jiangsu, China | Brand Name | JINGJIU | |
| Model Number | several models | Dimension(L*W*H) | according to the machines | |
| Weight | according to the machines | Certification | ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
cooking oil filling machine1.filling accuracy 1% ,high filling speed
2.filling cooking oil,edible oil,motor oil liquid
More information please login onto our website.
There are several models for different filling capacity. These oil filling machine aslo can filling shampoo,lotion,pesticides,and other high-viscous liquid.
The machines use PLC control system, famous brand electrical elements, SUS304 and high quality 316. They have high filling accuracy,superior speed.And, we have excellent competitive prices.
| Item No | CCG500-8 Automatic Piston Filling Machine | CCG1000-10 Automatic Piston Filling Machine | CDP- 8W-25L weighting & Filling Machine | CLWG-8B Weighting & Filling Machine | CDP- 1W-250L weighting & Filling Machine |
| Overall Size | 2000 ×1000 × 2200mm | 2000×1000× 2200mm | 2500×2450 × 2500mm | 2400 ×1200 × 2200mm | 600 ×800× 2800mm |
| Filling Head | 8 (4/6/8/10/12/16 heads can be selected) | 10 (4//6/8/10/12 heads can be selected) | 8 (4 heads can be selected ) | 8 heads (4//6/8/10/12 heads can be selected) | 1 |
| Application | Bottle dia 60-180mm | bottle dia 50-110mm | L (180-300) × W (120-250)×H(280-450)mm | bottle diameter:40-100mm | 50-250L barrel shape(Max. dia 600mm) |
| Filling Capacity | 50-500ml | 100-1000ml | 5-25L | 500-5000ml | 50-250L |
| Application | viscous liquid,ex. All kinds of oil,soy sauce, shampoo,pesticide, lotion,etc. | ||||
| Filling speed | about 4000bph | about 3600bph | 400-800 barrels / hour (take 5L as an exaple) | about 3000 bph | about 20 barrels / hour (take 250L as an exaple) |
| Measure Precision | ±1% | about ±1% | about ±0.03% | about ±0.03% | about ±0.03% |
| Voltage | 380V/220V | 380V/220V | 380V/220V | 380V/220V | 380V/220V |
| Power | 1.5 Kw | 1Kw | 4 Kw | 2.5 Kw | 1.5 Kw |
| Air-consuming | 0.55-0.65MPA | 0.55-0.65MPA | 0.55-0.65MPA | 0.6MPA | 0.6MPA |
| Weight | 500 kg | 600 kg | 800 kg | 500 kg | 300 kg |
| Feature | 1.mitsubishi PLC,colors creen,eco-friendly frame 2.filling blocker (prevent leaking ,dropping and drawing) ,can diving filling ( this function should be selected) 3.No need to change any components, easy to realize changing the bottle types by simple adjusting 4.international famous brand electical elements, PTEF hose, SUS 304/316 5.Counting detection& filling detection,real-time alarm | ||||
| piston filling way | intelligent weighing feedback system to realize the real unmanned debugging to ensure much more precise filling | ||||
| can carry out special configuration according to customers’ requirements (material airtight , heating, sterilizing etc) | Conveying design-Adopts rollway conveying model, saving time and labor | ||||
