CCG1000-16B Automatic Piston Filling Machine
- Shanghai
- T/T
You May Like
-
50ml-250L Automatic cooking oil filling machines
-
20ml-250L(20-100ml,50-500ml,100-1000ml,1-5L,5-30L,50-250L) Automatic cooking oil fillling machine
-
1L- 250L(1-5L,5-30L,50-250L) Automatic bucket oil filling machine
-
100-1000ml automatic bottle lotion filling machine made in china
-
CCG-6 Automatic Injection Filling Machine
-
CDP-24S (Double Rows) In-line Liquid Filling Machine
Product Details
Condition | New | Application | Beverage, Chemical, Commodity, Food, Medical, Other, Beverage, Chemical, Commodity, Food, Medical, Agrochemical | |
Packaging Type | Barrel, Bottles, Cans, Other, Barrel, Bottles, Cans, Jar | Packaging Material | Glass, Metal, Plastic, Other, Glass, Metal, Plastic, PET | |
Automatic Grade | Automatic | Driven Type | Electric | |
Voltage | 3 phase 4 wire, 220V/380V | Power | 1Kw | |
Place of Origin | Jiangsu, China | Brand Name | JING JIU | |
Model Number | CCG1000-16B | Dimension(L*W*H) | (L) 3000mm x (W) 1100mm x (H) 2200mm | |
Weight | 800 Kg, 800 Kg | Certification | ISO9001 & ISO14000 | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Main characteristic:
This automatic filling piston filler is mainly used for viscosity liquid filling & applicable for different shape containers, wide used in Chemical, Food, Pharmaceutical, Oil and other many industries. The main machine is composed of piston filler, inside hopper. It can be connected with capping machine, labeling machine, date/ batch coding machine, etc to perform a complete production line.
1. This machine adopts servo ball-screw system to drive the piston cylinder, which can fill high viscosity material, such as Oil, Sauce, Ketchup, Honey, Lubricant oil, etc;
2. Heating & Agitating device inside hopper is optional according to production request, max heating temperature to 40°c to helps melt the filling materials.
3. If filling material is a foamy liquid, diving function device is optional to sure no overflowing while filling.
4. Machine automatic self-clean function is optional. Use the pneumatic diaphragm pumps draw the clean solvent into filling machine hopper, by cycle filling to clean the hopper and filling nozzles.
5. The PLC programmable system was applied, and use color touch screen to form the control center, automatically adjust the filling speed. The control center language can be set to English, Latin, Polish, Japanese, Chinese, Korean, etc.
6. The stainless stell, non-poisonous & anti-corrosive PTEF hose are applicable for excellent durability and sanitation compliance.
Technical Parameters:
Filling Nozzles | 16 heads (can be selected more or less according to production requirements) |
Filling Volume | 50ml ~1000ml |
Suitable Bottle Opening | Φ 50mm ~ Φ 110mm |
Filling Speed | ≤ 6400 bottles / hour (200ml water) |
Voltage | 3 phase 4 wire, 220V/380V |
Power | 1Kw |
Air Pressure | 0.55-0.65Mpa |
Air Consumption | 0.6 ~ 0.9 m3/min |
Material | Stainless Steel 316 & 304 (upon request) |
Precision | ≤±1% |
Dimension | (L) 3000mm x (W) 1100mm x (H) 2200mm |
Weight | 800 Kg |
Country Origin | China |
Suitable Products:
CCG1000-16B Automatic Piston Filling Machine
01. High Efficiency/ Low cost --- >
- High precision of packing measuring
- High qualified rate, high capacity, fast changing
- Less labor, simple operation, easy maintenance
02. Clean working --- >
- No drip, easy to clean, no dust or odor
- Excellent durability and sanitation compliance
- Outside: Standard Export Wooden Case Pack
- Inner: Stretch Film
1. Technicial guidance & pre-maintain;
2. Quality guarantee for 1 year.
3. Able to send engineer to install & maintain. (Hotel & delivery fee paid by customer);
4. You are welcome to share us the sample to test machine;
