GH-CNC50 CNC automatic spring roll machine

FOB Price

USD $1 - $1 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	ADTECH
Model Number	GH-CNC50

1) A automatic CNC automatic spring roll machine;
2) Used to make wire molding;
3) CNC spring machine with high precision .

1.GH-CNC50 4/6-axis cnc universal spring machine consists of cam axis, wire feeding axis, rotation core and rolling axis. The mechanical part has eight sets-group slide rails,the crank and the cam rotation axis. The winch and cam rotation have three mechanical action types: extrusion, punching and molding.
2.The computerized cam rotation system can be set from 0.1~359.9". Every two wire feeding wheels is one group,there are three groups.
3.GH-CNC50 machine is equipped with ADT-CNC820 computer. The computer system can save 1000 material numbers. Axis location, feeding data, production speed and production output are displayed on the screen. The program data can be set and changed easily.
4.The rotation core system is installed on the axis. The axis can rotate leftwards and rightwards. The rolling axis is installed on the sliding house. The cam rotate is up to 360". more than that can come leftwards and rightwards or the rotation of the cam in a specific. Optional accessories: Cutting tool, rolling axis.

Technical paremeters for automatic spring roll machine GH-CNC50:

Model	GH-CNC50
Axis	4 or 6 Axis
Diameter	2.0~4.5mm
Max Feeding Dia	300mm
Max Feeding Length	unlimited
Max production speed	50RPM
Probe	4set
Cam Servo Motor	5.5kw
Wire Feed Servo Motor	7.0kw
Axis Servo Motor	1.5kw
Coiling Axis (optional accessories)	1.0kw
Power AC	three-phase 380V
Dimension	1800 X 1300 X 2100mm
Weight	3500kg
