Home > Products > Full HD Video Conference Camera System > 20x Optical Zoom 2.0MP Full HD PTZ Pant Tilt Zoom Color Video Conference Camera(SVC-HDD14)
20x Optical Zoom 2.0MP Full HD PTZ Pant Tilt Zoom Color Video Conference Camera(SVC-HDD14)
- Shenzhen China
 - T/T D/P D/A Credit Card PayPal

You May Like
-


10x Optical Zoom, Acutelogic Brand, HD Color Video Camera (Pan/Tilt/Zoom 2.1 Megapixel Full HD Video Conference Camer(SVC-HDB19)
 -


10x Optical Zoom Lens 2.0 Megapixel Full HD HDMI Output Video Conference Camera(SVC-HDA10)
 -


20x Optical Zoom 2.0 Megapixel Full HD SDI Color Video Pan Tilt Zoom PTZ Conference Camera System(SVC-HDD15)
 -


HD 30X Optical Zoom Lens Color Video PTZ Camera 2.14 Megapixel Full HD Video Conference Camera(SVC-HDD24
 -


USB Conference Microphone for Video Conference System(SPK-C330)
 -


480TVL USB Color PTZ Video Conference Camera(SVC-HA03-CN-USB)

Product Details
| Place of Origin | Guangdong, China | Brand Name | SMTSEC | |
| Model Number | SVC-HDD14 | Type | Digital Camera | |
| Style | Dome Camera | Sensor | CCD | |
| Technology | Infrared | Special Features | Other, Color Video PTZ Camera |
Product Description
20x Optical zoom 2.0MP Full HD PTZ pant tilt zoom Color Video conference Camera(SVC-HDD14)
2.0 Megapixel Full HD Camera experience 1080p@60 vivid images, equipped with which is 20x optical zoom lens, enhancing your video conferencing, distance learning, training meeting or courtrooms with natural and smooth video images. TheHD-SDI/DVI/HDMI Video output interface is suited for Web conferencing software or codec which provide high-quality video display.
| Model No. | SVC-HDD14 | |
| Image | Image Sensor | 1/2.8’’ Progressive CMOS |
| Sensor | Effective Pix | 2.0 Megapixel |
| Min. Illumination | 0.1 Lux at F1.6 | |
| White balance | Auto/Manual | |
| Gain control | Auto/Manual | |
| Backlight compensation | On/Off | |
| Shutter speed | 1/1 - 1/10,000S | |
| S/N ratio | >50db | |
| Lens | Focus | f=4.7-94mm |
| Iris | Auto/Manual | |
| Lens | 20x Optical zoom | |
| Horizontal view angle | 70.96°(W)~4°(T) | |
| Video output | HD-SDI CVBS DVI-I | |
| Video Output Mode | 1080P60, 1080P50,1080P30,1080P25, | |
| 720P60,720P50,720P30,720P25,PAL/NTSC | ||
| PTZ Control Interface | RS-232C, RS-485 (Bidirectional) | |
| Control Protocol | VISCA,PELCO-D | |
| baud rate | 9600/38400bps | |
| patrol line | 4 cruise sequence | |
| preset position | 64 preset positions | |
| Speed Match | Pan/Tilt movement speed depends on camera module zoom in/out | |
| OSD Menu | Access to OSD Menu and adjust camera module parameters | |
| Image auto flip | Support Horizontal/Vertical image flip | |
| Pan movement speed | 1-200°/Second | |
| Tilt movement speed | 1-150°/Second | |
| Pan movement range | Pan: 0-355° | |
| Tilt movement range | Up: 90°, Down: 45° | |
| Pan scanning automatically | Support Pan scanning automatically | |
| Boundary scanning | 0-355°(programmable) | |
| Remote controller | IR Wireless Remote controller P/T/Z | |
| Power supply | DC12V,2A | |
| Work Temperature | 0-50℃ | |
| Humidity | 0-95%RH | |
| LxWxH | 250mm x 140mm x 154mm | |
| Weight | 1380g | |
| Accessories kits in package: | ||
| 1x SVC-HDD14 Video Camera | ||
| 1x DC 12V/2A Power Adaptor | ||
| 1x User’s manual | ||
| 1x Installation brackets & screws | ||
China Post (10-30 days)
EMS (5-15 working days)
DHL (3-5 working days)
UPS (3-5 working days)
•The most reliable, affordable way of shipping method deponds on your address.
•Online tracking number will be emailed to buyer through email.
•We dont take any responsibility for any custom delay.
•All products have been checked and packaged in good condition before dispatch.
•All products have 1 year warranty.
