2016 New Arrival SIP-TM05W Indoor Wireless Cube P2P 0.3 MegaPixel Color CMOS 720P IP Cctv Camera

Model

SIP-TM05W

Type

Indoor Wireless Cube P2P IP Camera

Camera

Image sensor

1/4 inch 0.3MegaPixel Color CMOS Image Sensor

SNR

≥50dB

Minimum Illumination

0.3Lux

Sensor function

Auto White Balance,Auto Exposure,Automatic Gain

Lens

Standard: 3.6mm

IR-CUT

built in IR-CUT, no color cast in day, clearer image effect at night

IR

12pcs  Φ5  LEDs  IR distance: 10m

Video

Compression Format

H.264

Resolution

VGA(640X480)/QVGA(320×240)

Maximum frame rate

30fps

Bit Rate

128Kbps~1Mbps

Adjustment

light intensity,contrast ratio,saturation level are adjustable.

Audio

Encode formats

ADPCM

Input

Built in microphone

Output

one channel linear output,normal connector Of 3.5mm

Network

Socket

RJ-45   10/100Mb   self-adaptable Ethernet slot

Protocol

TCP/IP,HTTP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,PPPoE,P2P etc

WIFI

WIFI 802.11 b/g/n

Visitors Online

Support 8 visitors viewing on line at the same time

System

Operation system

Embedded Linux OS

System security

Supports three-level account, password, user multi-level authority management

DDNS

Free DDNS

Features

View by phone

Support IPhone and android Mobile phone view

Monitor Advantage

Support  Iphone, Android, Computer monitor. Miscrosoft certification plugin

UID Technology

UID scan technology applied, easy to operate, and highly confidential.

Easy operation

Sever cluster Plug & Play technology, penetration degree can be 99%,applicable toany complex network surroundings.

Mobile Platform

No need to install software, Multi-screen monitoring and managing by mobile phone,alarming,viewing.

View on PC

support windows system

Super Client

1,4,9,16,25,36, 64,81-channel , no user limited , centralized monitor, remote record and playback

Alarm Detection

Support motion detecting ,Settings for sensitivity  detection

Alarm action

E-mail pictures /upload video by FTP/messages alarm (coordinate to server)

Other

Power

DC 5V

Comsumption

<8W

Temperature

-10~75℃

Humidity

10%~85%

Package size

200X120X179mm

Net Weight

0.6kg
