Home > Products > Indoor Rental LED Display > SMD 3528 display
SMD 3528 display
- Hong Kong/Shenzhen
- T/T
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | LAMP | |
| Type | Other | Application | Indoor | |
| Max Resolution | 62500pixel/㎡ | Viewing Angle | 140°/140° | |
| Pixel Pitch | 7.62mm | Color | RGB | |
| Contrast Ratio | 3500:1 | Brightness | 2000-3500cd/㎡ | |
| Response Time | 0.01S | Input Voltage | AC110/230 |
Product Description
Specifications
1.slim display2.light-weight,modular design
3.accurate color uniformity and smoother, ficker-free video
4.ulimate display
Main Features
Broadcasting standard
Meet industry top quality requirements, high refresh rate, super image quality and color uniformity, high contrast ratio.
Full-Depth Calibration
Optimize picture uniformity with dot-to-dot calibration. Enable mix usage of products made of different batch.
Super light cabinets
a lighter aluminum cabinet makes it ideal for setup and teardown as well as transportation.
Easy rigging system
Each cabinet contain a strong rigging system to enable easy rigging and adjustments. Unique latching device can keep all display panels on same horizontal line, it also keep the panel as a whole without any aperture.
Application
1. Stage venues
2. Entertainment venues
3. Sports arenas
4. Commercial advertising
Specification
Pixel pitch(mm) | P4 | P5 | P6 | P7.62 |
Pixels Configuration | 1R,1PG,1PB | 1R,1PG,1PB | 1R,1PG,1PB | 1R,1PG,1PB |
Module Dimension | 128 × 128 | 160 × 160 | 192 × 96 | 244 × 122 |
Module Resolution | 32 × 32 | 32 × 32 | 32 × 16 | 32 × 16 |
Cabinet Dimension |
| 640 × 640 | 768 × 576 | 976 ×732 |
488 × 488 | ||||
Cabinet Resolution |
| 128 × 128 | 128 × 96 | 128 × 96 |
64 × 64 | ||||
Density (pixels / M2) | 62500 | 40,000 | 27,777 | 17,221 |
Brightness Density (cd/m2) | 4000 | 2600 | 2400 | 1800 |
Drive mode | 1/8 | 1/8 | 1/8 | 1/4 |
Best Viewing distance (m) | 4 ~ 20 | 3 ~ 100 | 3 ~ 100 | 5 ~ 100 |
Power consumption (Average) | 800 | 648 | 450 | 420 |
Power consumption | 1600 | 1600 | 1130 | 1050 |
Viewing angle | Horizontal angle: 120 degree ; Vertical angle: 120 degree | |||
Gray scale | 4096 gray scale in each Red,Green,Blue color | |||
Kinds of Color | 68.7 billion kinds | |||
Ingress Protection | Front IP40 , Rear IP30 | |||
Refresh Velocity | 60 frame/sec | |||
Refresh Rate | 300HZ | |||
Display Life | 100,000 hours | |||
Display MTBF | 10000 hours | |||
Blind Pixels Rate | 0.0003 | |||
Working Voltage | AC220V±15% , 47~64HZ | |||
Effective Control Distance | 100m (kind 5 cable) / 1000m or more (Optical fiber) | |||
Operation temperature | - 30°C ~ + 60°C | |||
Operation Humidity | 10% ~ 90% RH | |||
System Diagram
